VLR130

Back
Family Spec Sheet
Narrow Distance Narrow Distance
Wide Distance Wide Distance
10W20W30W40W50W

IP67. Class I. IK09. Marine-grade, all aluminum construction. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Linear PMMA LED lens, PMMA cover. 4 ft connecting cable, UV stabilized, PVC free. Integral LED driver; separate LED driver available instead, on request at time of order. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation and can be tilted up to 180°.
Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Eigenschaften

Material

GehäuseMarine-grade, all-aluminium construction
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone rubber gasket
SchlagfestigkeitIK09
SchutzartIP67
AbdeckungPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberIntegral 0-10V LED driver
Kabel4 ft of flexible PVC-free cable
Leistungsfaktor
NetzIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Überspannungsschutz

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h

Lichtverteilung

Leistung (W)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
187-0003symmetric linear, medium beam [LM]LED-48/30W / 225 mA - 3000 K3210.680electronic gear3.25
187-0007symmetric linear, narrow beam [LN]LED-48/30W / 225 mA - 3000 K3151.980electronic gear3.25
187-0011symmetric linear, very narrow beam [LVN]LED-48/30W / 225 mA - 3000 K3608.980electronic gear3.25
187-0025symmetric linear, wide beam [LW]LED-48/30W / 225 mA - 3000 K2873.680electronic gear3.25
187-0039symmetric linear, medium beam [LM]LED-48/30W / 225 mA - 4000 K3210.680electronic gear3.25
187-0040symmetric linear, narrow beam [LN]LED-48/30W / 225 mA - 4000 K3151.980electronic gear3.25
187-0041symmetric linear, very narrow beam [LVN]LED-48/30W / 225 mA - 4000 K3608.980electronic gear3.25
187-0042symmetric linear, wide beam [LW]LED-48/30W / 225 mA - 4000 K2873.680electronic gear3.25
187-0537symmetric linear, wide beam [LW]LED-48/30W / 225 mA - 2700 K2873.680electronic gear3.25
187-0538symmetric linear, medium beam [LM]LED-48/30W / 225 mA - 2700 K3210.680electronic gear3.25
187-0539symmetric linear, narrow beam [LN]LED-48/30W / 225 mA - 2700 K3151.980electronic gear3.25
187-0540symmetric linear, very narrow beam [LVN]LED-48/30W / 225 mA - 2700 K3608.980electronic gear3.25
187-0586symmetric linear, wide beam [LW/IW]LED-48/30W / 225 mA - 2700 K1277.380electronic gear3.25
187-0496symmetric linear, wide beam [LW/IW]LED-48/30W / 225 mA - 3000 K1277.380electronic gear3.25
187-0497symmetric linear, wide beam [LW/IW]LED-48/30W / 225 mA - 4000 K1277.380electronic gear3.25
187-0499symmetric linear, medium beam [LM/IW]LED-48/30W / 225 mA - 4000 K1603.280electronic gear3.25
187-0587symmetric linear, medium beam [LM/IW]LED-48/30W / 225 mA - 2700 K1603.280electronic gear3.25
187-0498symmetric linear, medium beam [LM/IW]LED-48/30W / 225 mA - 3000 K1603.280electronic gear3.25
187-0500symmetric linear, narrow beam [LN/IW]LED-48/30W / 225 mA - 3000 K1670.580electronic gear3.25
187-0588symmetric linear, narrow beam [LN/IW]LED-48/30W / 225 mA - 2700 K1670.580electronic gear3.25
187-0501symmetric linear, narrow beam [LN/IW]LED-48/30W / 225 mA - 4000 K1670.580electronic gear3.25
Showing 1 to 21 of 21 Entries
