VLR120

Family Spec Sheet

IP67. Class I. IK09. Marine-grade, all aluminum construction. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Linear PMMA LED lens, PMMA cover. 4 ft connecting cable, UV stabilized, PVC free. Integral LED driver; separate driver on request at time of order. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation and can be tilted up to 180°. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Colors

Material

Body: Marine-grade, all-aluminium construction

Fasteners: PCS Polymer Coated Stainless Steel Hardware

Gasket:

Impact Protection: IK09

Ingress Protection: IP67

Finish: Powdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019

Corrosion Protection: 5CE

Mounting:

Electrical

Ballast / Driver: LED driver with DALI Interface

Cable: 1.2 m of flexible PVC free cable

Power Factor:

Power Supply: Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.

Surge Protection:

Additional Information

Lifetime: Ta=25°/40° L90B10 > 90000h

Light Distribution

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
187-0002	symmetric linear, medium beam [LM]	LED-32/20W / 225 mA - 3000 K	2140.4	80
187-0006	symmetric linear, narrow beam [LN]	LED-32/20W / 225 mA - 3000 K	2101.3	80
187-0010	symmetric linear, very narrow beam [LVN]	LED-32/20W / 225 mA - 3000 K	2405.9	80
187-0024	symmetric linear, wide beam [LW]	LED-32/20W / 225 mA - 3000 K	1915.7	80
187-0035	symmetric linear, medium beam [LM]	LED-32/20W / 225 mA - 4000 K	2140.4	80
187-0036	symmetric linear, narrow beam [LN]	LED-32/20W / 225 mA - 4000 K	2101.3	80
187-0037	symmetric linear, very narrow beam [LVN]	LED-32/20W / 225 mA - 4000 K	2405.9	80
187-0038	symmetric linear, wide beam [LW]	LED-32/20W / 225 mA - 4000 K	1915.7	80
187-0534	symmetric linear, wide beam [LW]	LED-32/20W / 225 mA - 2700 K	1915.7	80
187-0460	symmetric linear, medium beam [LM]	LED-32/20W / 225 mA - 2700 K	2140.4	80
187-0535	symmetric linear, narrow beam [LN]	LED-32/20W / 225 mA - 2700 K	2101.3	80
187-0536	symmetric linear, very narrow beam [LVN]	LED-32/20W / 225 mA - 2700 K	2405.9	80
187-0581	symmetric linear, wide beam [LW/IW]	LED-32/20W / 225 mA - 2700 K	851.5	80
187-0486	symmetric linear, wide beam [LW/IW]	LED-32/20W / 225 mA - 3000 K	851.5	80
187-0487	symmetric linear, wide beam [LW/IW]	LED-32/20W / 225 mA - 4000 K	851.5	80
187-0582	symmetric linear, medium beam [LM/IW]	LED-32/20W / 225 mA - 2700 K	1068.8	80
187-0488	symmetric linear, medium beam [LM/IW]	LED-32/20W / 225 mA - 3000 K	1068.8	80
187-0489	symmetric linear, medium beam [LM/IW]	LED-32/20W / 225 mA - 4000 K	1068.8	80
187-0583	symmetric linear, narrow beam [LN/IW]	LED-32/20W / 225 mA - 2700 K	1113.7	80
187-0490	symmetric linear, narrow beam [LN/IW]	LED-32/20W / 225 mA - 3000 K	1113.7	80
187-0491	symmetric linear, narrow beam [LN/IW]	LED-32/20W / 225 mA - 4000 K	1113.7	80

Showing 1 to 21 of 21 Entries
