VLR100 series

VLR140

Static White

Choose a variant:

Symmetric
Asymmetric

Choose a family:

?W | VLR110 ?W | VLR120 ?W | VLR130 ?W | VLR140 ?W | VLR150
Home
Products
Surface Mounted Wall Luminaires
VLR140
Family Spec Sheet Installation Instructions More Downloads

IP67. Class I. IK09. Marine-grade, all aluminum construction. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Linear PMMA LED lens, PMMA cover. 4 ft connecting cable, UV stabilized, PVC free. Integral LED driver; separate LED driver available instead, on request at time of order. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation and can be tilted up to 180°. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

VLR140 Schematics
Colours
RAL9004 Black
RAL9007 Grey Metallic
RAL9016 White
RAL8019 Dark Bronze
Material
BodyMarine-grade, all-aluminium construction
FastenersPCS Polymer Coated Stainless Steel Hardware
GasketSilicone rubber gasket
Impact ProtectionIK09
Ingress ProtectionIP67
FinishPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019
Corrosion Protection5CE
Electrical
Ballast / DriverLED driver with 0-10V Interface
Cable4 ft of flexible PVC-free cable
Power SupplyIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Additional Information
LifetimeTa=25°/40° L90B10 > 90000h

Wattage

To
Part-IDLight DistributionLight SourceLumenCRISpecificationsPhotometrics
TextPDF
187-0004symmetric linear, medium beam [LM]LED-64/40W / 225 mA - 3000 K4280.880
187-0008symmetric linear, narrow beam [LN]LED-64/40W / 225 mA - 3000 K4202.580
187-0026symmetric linear, wide beam [LW]LED-64/40W / 225 mA - 3000 K3831.580
187-0043symmetric linear, medium beam [LM]LED-64/40W / 225 mA - 4000 K4280.880
187-0044symmetric linear, narrow beam [LN]LED-64/40W / 225 mA - 4000 K4202.580
187-0045symmetric linear, very narrow beam [LVN]LED-64/40W / 225 mA - 4000 K4811.980
187-0046symmetric linear, wide beam [LW]LED-64/40W / 225 mA - 4000 K3831.580
187-0012symmetric linear, very narrow beam [LVN]LED-64/40W / 225 mA - 3000 K4811.980
187-0541symmetric linear, wide beam [LW]LED-64/40W / 225 mA - 2700 K3831.580
187-0542symmetric linear, medium beam [LM]LED-64/40W / 225 mA - 2700 K4280.880
187-0543symmetric linear, narrow beam [LN]LED-64/40W / 225 mA - 2700 K4202.580
187-0544symmetric linear, very narrow beam [LVN]LED-64/40W / 225 mA - 2700 K4811.980
187-0591symmetric linear, wide beam [LW/IW]LED-64/40W / 225 mA - 2700 K170380
187-0506symmetric linear, wide beam [LW/IW]LED-64/40W / 225 mA - 3000 K170380
187-0507symmetric linear, wide beam [LW/IW]LED-64/40W / 225 mA - 4000 K170380
187-0592symmetric linear, medium beam [LM/IW]LED-64/40W / 225 mA - 2700 K2137.680
187-0508symmetric linear, medium beam [LM/IW]LED-64/40W / 225 mA - 3000 K2137.680
187-0509symmetric linear, medium beam [LM/IW]LED-64/40W / 225 mA - 4000 K2137.680
187-0593symmetric linear, narrow beam [LN/IW]LED-64/40W / 225 mA - 2700 K2227.480
187-0510symmetric linear, narrow beam [LN/IW]LED-64/40W / 225 mA - 3000 K2227.480
187-0511symmetric linear, narrow beam [LN/IW]LED-64/40W / 225 mA - 4000 K2227.480
Showing 1 to 21 of 21 Entries
