VLR100 series

VLR120 [LA10]

Static White

Choose a variant:

Symmetric
Asymmetric

Choose a family:

?W | VLR120-LA10 ?W | VLR130-LA10 ?W | VLR140-LA10
Home
Products
Surface-Mounted Wall Luminaires
VLR120 [LA10]
Family Spec Sheet Installation Instructions More Downloads

IP67. Class I. IK09. Marine-grade, all aluminum construction. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Linear PMMA LED lens, PMMA cover. 4 ft connecting cable, UV stabilized, PVC free. Integral LED driver; separate LED driver available instead, on request at time of order. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation and can be tilted up to 180°. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

VLR120 [LA10] Schematics
Colours
RAL9004 Black
RAL9007 Grey Metallic
RAL9016 White
RAL8019 Dark Bronze
Material
BodyMarine-grade, all-aluminium construction
FastenersPCS Polymer Coated Stainless Steel Hardware
Impact ProtectionIK09
Ingress ProtectionIP67
FinishPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019
Corrosion Protection5CE
Electrical
Ballast / DriverLED driver with DALI Interface
Cable4 ft of flexible PVC-free cable
Power SupplyIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Additional Information
LifetimeTa=25°/40° L90B10 > 90000h
Part-IDLight DistributionLight SourceLumenCRISpecificationsPhotometrics
TextPDF
187-0014asymmetric linear, wallwash [LA10]LED-32/20W / 225 mA - 3000 K2049.880
187-0329asymmetric linear, wallwash [LA10]LED-32/20W / 225 mA - 4000 K2049.880
187-0549asymmetric linear, wallwash [LA10]LED-32/20W / 225 mA - 2700 K2049.880
Showing 1 to 3 of 3 Entries
