VLR110

VLR110

Family Spec Sheet

IP67. Class I. IK09. Marine-grade, all aluminum construction. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Linear PMMA LED lens, PMMA cover. 4 ft connecting cable, UV stabilized, PVC free. Separate LED driver. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation and can be tilted up to 180°. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

VLR110 Schematics
Colors
RAL9004 Black
RAL9006 White
RAL9007 Grey Metallic
RAL7016 Anthracite grey
RAL9016 White
RAL8019 Dark Bronze
Powdercoat finish available in 35 different colours
Material
BodyMarine-grade, all-aluminium construction
FastenersPCS Polymer Coated Stainless Steel hardware
GasketSilicone rubber gasket
Impact ProtectionIK09
Ingress ProtectionIP67
FinishPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019
Corrosion Protection5CE Corrosion protection system
Mounting
Electrical
Ballast / DriverSeparate LED driver with 0-10V Interface
Cable4 ft connecting cable
Power Factor
Power SupplyIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Surge Protection
Additional Information
LifetimeTa=25°/40° L90B10 > 90000h
Part-IDLight DistributionLight SourceLumenCRIOpen DataPDFIES, LDT, ULD
187-0001symmetric linear, medium beam [LM]LED-16/10W / 225 mA - 3000 K1070.280
187-0005symmetric linear, narrow beam [LN]LED-16/10W / 225 mA - 3000 K1050.680
187-0009symmetric linear, very narrow beam [LVN]LED-16/10W / 225 mA - 3000 K120380
187-0023symmetric linear, wide beam [LW]LED-16/10W / 225 mA - 3000 K957.980
187-0031symmetric linear, medium beam [LM]LED-16/10W / 225 mA - 4000 K1070.280
187-0032symmetric linear, narrow beam [LN]LED-16/10W / 225 mA - 4000 K1050.680
187-0033symmetric linear, very narrow beam [LVN]LED-16/10W / 225 mA - 4000 K120380
187-0034symmetric linear, wide beam [LW]LED-16/10W / 225 mA - 4000 K957.980
187-0531symmetric linear, wide beam [LW]LED-16/10W / 225 mA - 2700 K957.980
187-0459symmetric linear, medium beam [LM]LED-16/10W / 225 mA - 2700 K1024.980
187-0532symmetric linear, narrow beam [LN]LED-16/10W / 225 mA - 2700 K1050.680
187-0533symmetric linear, very narrow beam [LVN]LED-16/10W / 225 mA - 2700 K120380
187-0576symmetric linear, wide beam [LW/IW]LED-16/10W / 225 mA - 2700 K425.880
187-0476symmetric linear, wide beam [LW/IW]LED-16/10W / 225 mA - 3000 K425.880
187-0477symmetric linear, wide beam [LW/IW]LED-16/10W / 225 mA - 4000 K425.880
187-0577symmetric linear, medium beam [LM/IW]LED-16/10W / 225 mA - 2700 K534.480
187-0478symmetric linear, medium beam [LM/IW]LED-16/10W / 225 mA - 3000 K534.480
187-0479symmetric linear, medium beam [LM/IW]LED-16/10W / 225 mA - 4000 K534.480
187-0578symmetric linear, narrow beam [LN/IW]LED-16/10W / 225 mA - 2700 K556.880
187-0480symmetric linear, narrow beam [LN/IW]LED-16/10W / 225 mA - 3000 K556.880
187-0481symmetric linear, narrow beam [LN/IW]LED-16/10W / 225 mA - 4000 K556.880
Showing 1 to 21 of 21 Entries
