IP67. Class I. IK09. Marine-grade, all aluminum construction. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Linear PMMA LED lens, PMMA cover. 4 ft connecting cable, UV stabilized, PVC free. Integral LED driver; separate LED driver available instead, on request at time of order. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation and can be tilted up to 180°. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)
Colors
RAL9004 Black
RAL9006 White
RAL9007 Grey Metallic
RAL7016 Anthracite grey
RAL9016 White
RAL8019 Dark Bronze
Powdercoat finish available in 35 different colours
Material
| Body | Marine-grade, all-aluminium construction |
| Fasteners | PCS Polymer Coated Stainless Steel Hardware |
| Gasket | Silicone rubber gasket |
| Impact Protection | IK09 |
| Ingress Protection | IP67 |
| Finish | Powdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019 |
| Corrosion Protection | 5CE |
| Mounting |
Electrical
| Ballast / Driver | Integral LED driver with DALI Interface |
| Cable | 4 ft of flexible PVC-free cable |
| Power Factor | |
| Power Supply | Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order. |
| Surge Protection |
Additional Information
| Lifetime | Ta=25°/40° L90B10 > 90000h |
- - - -
Accessories
| Item | Download | Mail Link |
|---|---|---|
| Product Images | ||
| Light Distributions | ||
| Install Instructions | ||
| Manual |
