FLC260 LED

Standard Projector

75 mm

IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. One cable gland, second gland for through wiring on request. CAD-optimized optics for superior illumination and glare control. Integral driver, thermally separated. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming on request.
A maximum of one internal optical accessory. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Eigenschaften

Material

Gehäuse	Marine-grade, die-cast aluminium alloy
Schrauben	PCS Polymer Coated Stainless Steel Hardware
Farben	Pending
Dichtung	Silicone CCG® Controlled Compression Gasket
Schlagfestigkeit	IK07
Schutzart	IP66
Abdeckung	Powdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019
Korrosionsschutz	5CE
Befestigung

Elektrik

LED Treiber	Integral EC electronic converter in thermally-separated compartment
Kabel	One cable entry, second cable entry on request. Request 0-10V to ensure control wires are connected.
Leistungsfaktor	> 0.9
Netz	Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Überspannungsschutz	Integral 10kV Surge Protector

Weitere Eigenschaften

Lifetime	Ta=25°/40° L90B10 > 90000h

Lichtverteilung

Lichtstrom (lm)

Leistung (W)

Farbtemperatur (K)

Artikelnummer	Lichtverteilung	Lichtquelle	Bemessungslichtstrom	CRI	Vorschaltgerät	Gewicht (kg)	Open Data (txt)	Datenblatt	IES, LDT, ULD
139-1806	symmetric, medium beam [M]	LED-36/72W / 700 mA - 3000 K	9457	80	electronic gear	38.58
139-1807	symmetric, medium beam [M]	LED-36/72W / 700 mA - 4000 K	10109.2	80	electronic gear	38.58
139-1808	symmetric, narrow beam [N]	LED-36/72W / 700 mA - 3000 K	8896.5	80	electronic gear	38.58
139-1809	symmetric, narrow beam [N]	LED-36/72W / 700 mA - 4000 K	9510.1	80	electronic gear	38.58
139-1811	symmetric, very narrow beam [VN]	LED-36/72W / 700 mA - 4000 K	10007.2	80	electronic gear	38.58
139-1791	symmetric, medium beam [M]	LED-36/108W / 1050 mA - 3000 K	14022.4	80	electronic gear	38.58
139-1792	symmetric, medium beam [M]	LED-36/108W / 1050 mA - 4000 K	14674.6	80	electronic gear	38.58
139-1793	symmetric, narrow beam [N]	LED-36/108W / 1050 mA - 3000 K	13191.4	80	electronic gear	38.58
139-1794	symmetric, narrow beam [N]	LED-36/108W / 1050 mA - 4000 K	13805	80	electronic gear	38.58
139-1795	symmetric, very narrow beam [VN]	LED-36/108W / 1050 mA - 3000 K	13881	80	electronic gear	38.58
139-1796	symmetric, very narrow beam [VN]	LED-36/108W / 1050 mA - 4000 K	14526.6	80	electronic gear	38.58
139-1797	symmetric, medium beam [M]	LED-36/155W / 1400 mA - 3000 K	17246.3	80	electronic gear	38.58
139-1798	symmetric, medium beam [M]	LED-36/155W / 1400 mA - 4000 K	18030.3	80	electronic gear	38.58
139-1799	symmetric, narrow beam [N]	LED-36/155W / 1400 mA - 3000 K	16236.7	80	electronic gear	38.58
139-1800	symmetric, narrow beam [N]	LED-36/155W / 1400 mA - 4000 K	16974.7	80	electronic gear	38.58
139-1801	symmetric, very narrow beam [VN]	LED-36/155W / 1400 mA - 3000 K	17400.1	80	electronic gear	38.58
139-1802	symmetric, very narrow beam [VN]	LED-36/155W / 1400 mA - 4000 K	18191.1	80	electronic gear	38.58
139-1955	symmetric, wide beam [W]	LED-36/72W / 700 mA - 3000 K	8972.1	80	electronic gear	38.58
139-1956	symmetric, wide beam [W]	LED-36/72W / 700 mA - 4000 K	9590.9	80	electronic gear	38.58
139-1959	symmetric, wide beam [W]	LED-36/108W / 1050 mA - 3000 K	13303.5	80	electronic gear	38.58
139-1960	symmetric, wide beam [W]	LED-36/108W / 1050 mA - 4000 K	13922.2	80	electronic gear	38.58
139-1964	symmetric, wide beam [W]	LED-36/155W / 1400 mA - 4000 K	17188.5	80	electronic gear	38.58
139-1963	symmetric, wide beam [W]	LED-36/155W / 1400 mA - 3000 K	16441.1	80	electronic gear	38.58
139-1810	symmetric, very narrow beam [VN]	LED-36/72W / 700 mA - 3000 K	9361.6	80	electronic gear	35.58
139-1795	linear spread, very narrow beam [VN]	LED-36/108W / 1050 mA - 3000 K	13228.8	80	electronic gear	38.58

Showing 1 to 25 of 58 Entries
