FLC240 LED
Family Spec SheetIP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. One cable gland, second gland for through wiring on request. CAD-optimized optics for superior illumination and glare control. Integral driver, thermally separated. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming on request. A maximum of one internal optical accessory. Optional 2200K version available, except [VNS] version, to be specified at time of order. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)
Colors
Material
| Body | Marine-grade, die-cast aluminium alloy |
| Fasteners | PCS Polymer Coated Stainless Steel Hardware |
| Gasket | Silicone CCG® Controlled Compression Gasket |
| Impact Protection | IK07 |
| Ingress Protection | IP66 |
| Finish | Powdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019 |
| Corrosion Protection | 5CE |
| Mounting |
Electrical
| Ballast / Driver | Integral EC electronic converter in thermally-separated compartment |
| Cable | One cable entry, second cable entry on request. Request 0-10V to ensure control wires are connected. |
| Power Factor | > 0.9 |
| Power Supply | Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order. |
| Surge Protection | Integral 10kV Surge Protector |
Additional Information
| Lifetime | Ta=25°/40° L90B10 > 90000h |
