RGBW/RGBA Color Changer. IP66, Class III. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. One cable gland. Second gland for through-wiring on request. Integral driver in separate driver box (constant current), prewired; to be ordered separately. CAD-optimized optics for superior illumination and glare control. OLC® One LED Concept. Factory-installed LED circuit board. Color Changer technology. DMX interface. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX – 9004 (Black) + XXX-XXXX (Accessory 1)

FLC210 LED COLOR CHANGER Schematics
Colors
Material

Body: Marine-grade, die-cast aluminium alloy

Fasteners: PCS Polymer Coated Stainless Steel Hardware

Gasket: CCG® Silicone rubber gasket

Impact Protection: IK07

Ingress Protection: IP66

Finish:

Corrosion Protection: 5CE

Mounting: Pre-assembled connection cable possible (0,4m, 1m, 1,5m, 3m or 6m)

Electrical

Ballast / Driver: DMX

Cable: One cable gland, second gland for through-wiring on request

Power Factor: > 0.9

Power Supply:

Surge Protection:

Additional Information

Lifetime: Ta=25° L90B10 > 90000h

:

:

Light Distribution

Delivered Lumen

To
Part-IDLight DistributionLight SourceLumenCRIOpen DataPDFIES, LDT, ULD
139-2408symmetric, wide beam [W]LED-3/12W - RGBW/4K771.920/80
139-2411symmetric, medium beam [M]LED-3/12W - RGBW/4K779.920/80
139-2410symmetric, wide beam [W]LED-3/12W - RGBA624.320
139-2413symmetric, medium beam [M]LED-3/12W - RGBA630.820
Showing 1 to 4 of 4 Entries
