IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. For 2200 K version available on request, except [EES] distribution.

FLC260 LED Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, die-cast aluminium alloy
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK07
Ingress ProtectionIP66
Corrosion Protection5CE
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-separated compartment
Additional Information
LifetimeTa=25° L90B10 > 90000h

Delivered Lumen

To

Wattage

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
139-1806symmetric, medium beam [M]LED-36/72W / 700 mA - 3000 K945780 ULD
139-1807symmetric, medium beam [M]LED-36/72W / 700 mA - 4000 K10109.280 ULD
139-1808symmetric, narrow beam [E]LED-36/72W / 700 mA - 3000 K8896.580 ULD
139-1809symmetric, narrow beam [E]LED-36/72W / 700 mA - 4000 K9510.180 ULD
139-1811symmetric, very narrow beam [EE]LED-36/72W / 700 mA - 4000 K10007.280 ULD
139-1791symmetric, medium beam [M]LED-36/108W / 1050 mA - 3000 K14022.480 ULD
139-1792symmetric, medium beam [M]LED-36/108W / 1050 mA - 4000 K14674.680 ULD
139-1793symmetric, narrow beam [E]LED-36/108W / 1050 mA - 3000 K13191.480 ULD
139-1794symmetric, narrow beam [E]LED-36/108W / 1050 mA - 4000 K1380580 ULD
139-1795symmetric, very narrow beam [EE]LED-36/108W / 1050 mA - 3000 K1388180 ULD
139-1796symmetric, very narrow beam [EE]LED-36/108W / 1050 mA - 4000 K14526.680 ULD
139-1797symmetric, medium beam [M]LED-36/155W / 1400 mA - 3000 K17246.380 ULD
139-1798symmetric, medium beam [M]LED-36/155W / 1400 mA - 4000 K18030.380 ULD
139-1799symmetric, narrow beam [E]LED-36/155W / 1400 mA - 3000 K16236.780 ULD
139-1800symmetric, narrow beam [E]LED-36/155W / 1400 mA - 4000 K16974.780 ULD
139-1801symmetric, very narrow beam [EE]LED-36/155W / 1400 mA - 3000 K17400.180 ULD
139-1802symmetric, very narrow beam [EE]LED-36/155W / 1400 mA - 4000 K18191.180 ULD
139-1955symmetric, wide beam [B]LED-36/72W / 700 mA - 3000 K8972.180 ULD
139-1956symmetric, wide beam [B]LED-36/72W / 700 mA - 4000 K9590.980 ULD
139-1959symmetric, wide beam [B]LED-36/108W / 1050 mA - 3000 K13303.580 ULD
139-1960symmetric, wide beam [B]LED-36/108W / 1050 mA - 4000 K13922.280 ULD
139-1964symmetric, wide beam [B]LED-36/155W / 1400 mA - 4000 K17188.580 ULD
139-1963symmetric, wide beam [B]LED-36/155W / 1400 mA - 3000 K16441.180 ULD
139-1810symmetric, very narrow beam [EE]LED-36/72W / 700 mA - 3000 K9361.680 ULD
139-1795linear spread, very narrow beam [EE]LED-36/108W / 1050 mA - 3000 K13228.880 ULD
139-1796linear spread, very narrow beam [EE]LED-36/108W / 1050 mA - 4000 K13844.180 ULD
139-1801linear spread, very narrow beam [EE]LED-36/155W / 1400 mA - 3000 K1627680 ULD
139-1802linear spread, very narrow beam [EE]LED-36/155W / 1400 mA - 4000 K17015.880 ULD
139-1810linear spread, very narrow beam [EE]LED-36/72W / 700 mA - 3000 K8921.880 ULD
139-1811linear spread, very narrow beam [EE]LED-36/72W / 700 mA - 4000 K9537.180 ULD
139-1791wallwashLED-36/108W / 1050 mA - 3000 K11645.280 ULD
139-1792wallwashLED-36/108W / 1050 mA - 4000 K12186.880 ULD
139-1797wallwashLED-36/155W / 1400 mA - 3000 K14322.380 ULD
139-1798wallwashLED-36/155W / 1400 mA - 4000 K14973.380 ULD
139-1806wallwashLED-36/72W / 700 mA - 3000 K7853.780 ULD
139-1807wallwashLED-36/72W / 700 mA - 4000 K8395.480 ULD
139-2230symmetric, wide beam [B]LED-36/155W / 1400 mA - 2700 K15544.380 ULD
139-2175symmetric, medium beam [M]LED-36/155W / 1400 mA - 2700 K16305.680 ULD
139-2231symmetric, narrow beam [E]LED-36/155W / 1400 mA - 2700 K1535180 ULD
139-2281symmetric, very narrow beam [EE]LED-36/155W / 1400 mA - 2700 K1645180 ULD
139-2254symmetric, wide beam [B]LED-36/108W / 1050 mA - 2700 K12684.780 ULD
139-2255symmetric, medium beam [M]LED-36/108W / 1050 mA - 2700 K13370.280 ULD
139-2256symmetric, narrow beam [E]LED-36/108W / 1050 mA - 2700 K12577.980 ULD
139-2274symmetric, very narrow beam [EE]LED-36/108W / 1050 mA - 2700 K13235.380 ULD
139-2257symmetric, wide beam [B]LED-36/72W / 700 mA - 2700 K8353.380 ULD
139-2258symmetric, medium beam [M]LED-36/72W / 700 mA - 2700 K8804.880 ULD
139-2259symmetric, narrow beam [E]LED-36/72W / 700 mA - 2700 K828380 ULD
139-2267symmetric, very narrow beam [EE]LED-36/72W / 700 mA - 2700 K8715.980 ULD
139-2258wallwashLED-36/72W / 700 mA - 2700 K7312.180 ULD
139-2267linear spread, very narrow beam [EE]LED-36/72W / 700 mA - 2700 K8306.580 ULD
Showing 1 to 50 of 60 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
270-9038Short post EM1-M16
