3G Vibration Certified.
IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. One cable gland, second gland for through wiring on request. CAD-optimized optics for superior illumination and glare control. Integral driver, thermally separated. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire.
Optional 2200 K version available. To be specified at time of ordering.
A maximum of one internal optical accessory.
Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately.
Example: XXX-XXXX-9004 (Black)
+ XXX-XXXX (Accessory 1)
Eigenschaften
Material
Gehäuse
Marine-grade, die-cast aluminium alloy
Schrauben
PCS Polymer Coated Stainless Steel Hardware
Farben
Pending
Dichtung
Silicone CCG® Controlled Compression Gasket
Schlagfestigkeit
IK07
Schutzart
IP66
Abdeckung
Powder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019.
Korrosionsschutz
5CE
Befestigung
Elektrik
LED Treiber
ECG in thermally-separated compartment
Kabel
One cable entry, second cable entry on request. Request 0-10V to ensure control wires are connected.
Leistungsfaktor
Netz
Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Überspannungsschutz
Integral 10kV Surge Protector
Weitere Eigenschaften
Lifetime
Ta=25°/40° L90B10 > 90000h
Lead Time
This is a new product release and may have an extended lead time.
----
Lichtverteilung
Lichtstrom (lm)
Farbtemperatur (K)
Artikelnummer
Lichtverteilung
Lichtquelle
Bemessungslichtstrom
CRI
Vorschaltgerät
Gewicht (kg)
Open Data (txt)
Datenblatt
IES, LDT, ULD
139-1999
symmetric, wide beam [W]
LED-6/12W / 700 mA - 3000 K
1492
80
electronic gear
9.50
139-2000
symmetric, wide beam [W]
LED-6/12W / 700 mA - 4000 K
1594.9
80
electronic gear
9.50
139-2009
symmetric, wide beam [W]
LED-6/18W / 1050 mA - 3000 K
2212.3
80
electronic gear
9.50
139-2010
symmetric, wide beam [W]
LED-6/18W / 1050 mA - 4000 K
2315.2
80
electronic gear
9.50
139-2024
symmetric, wide beam [W]
LED-6/26W / 1400 mA - 3000 K
2744.9
80
electronic gear
9.50
139-2025
symmetric, wide beam [W]
LED-6/26W / 1400 mA - 4000 K
2869.7
80
electronic gear
9.50
139-2001
symmetric, medium beam [M]
LED-6/12W / 700 mA - 3000 K
1533.6
80
electronic gear
9.50
139-2002
symmetric, medium beam [M]
LED-6/12W / 700 mA - 4000 K
1639.3
80
electronic gear
9.50
139-2011
symmetric, medium beam [M]
LED-6/18W / 1050 mA - 3000 K
2273.9
80
electronic gear
9.50
139-2012
symmetric, medium beam [M]
LED-6/18W / 1050 mA - 4000 K
2379.6
80
electronic gear
9.50
139-2026
symmetric, medium beam [M]
LED-6/26W / 1400 mA - 3000 K
2821.4
80
electronic gear
9.50
139-2027
symmetric, medium beam [M]
LED-6/26W / 1400 mA - 4000 K
2949.6
80
electronic gear
9.50
139-2003
symmetric, narrow beam [N]
LED-6/12W / 700 mA - 3000 K
1473.8
80
electronic gear
9.50
139-2004
symmetric, narrow beam [N]
LED-6/12W / 700 mA - 4000 K
1575.5
80
electronic gear
9.50
139-2013
symmetric, narrow beam [N]
LED-6/18W / 1050 mA - 3000 K
2185.4
80
electronic gear
9.50
139-2014
symmetric, narrow beam [N]
LED-6/18W / 1050 mA - 4000 K
2287
80
electronic gear
9.50
139-2028
symmetric, narrow beam [N]
LED-6/26W / 1400 mA - 3000 K
2711.6
80
electronic gear
9.50
139-2029
symmetric, narrow beam [N]
LED-6/26W / 1400 mA - 4000 K
2834.8
80
electronic gear
9.50
139-2005
symmetric, very narrow beam [VN]
LED-6/12W / 700 mA - 3000 K
1559.6
80
electronic gear
9.50
139-2006
symmetric, very narrow beam [VN]
LED-6/12W / 700 mA - 4000 K
1667.2
80
electronic gear
9.50
139-2015
symmetric, very narrow beam [VN]
LED-6/18W / 1050 mA - 3000 K
2312.6
80
electronic gear
9.50
139-2016
symmetric, very narrow beam [VN]
LED-6/18W / 1050 mA - 4000 K
2420.1
80
electronic gear
9.50
139-2030
symmetric, very narrow beam [VN]
LED-6/26W / 1400 mA - 3000 K
2869.2
80
electronic gear
9.50
139-2031
symmetric, very narrow beam [VN]
LED-6/26W / 1400 mA - 4000 K
2999.6
80
electronic gear
9.50
139-2007
symmetric, very narrow beam, 'sharp cut-off' [VNS]
