FLC200 series

FLC201 LED

Static White
Tunable White
Colour Changer

Choose a family:

6W | 75 mm | FLC201 6 – 12 W | 150 mm | FLC210 12 – 26W | 190 mm | FLC220 24 – 52W | 260 mm | FLC230 48 – 104W | 340 mm | FLC240 72 – 155W | 385 mm | FLC260
Home
Products
Floodlights
FLC201 LED
Family Spec Sheet Installation Instructions More Downloads

IP66, Class III. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. One factory installed flange plug M8 x 1.5. Cable length 10 ft. CAD-optimized optics for superior illumination and glare control. OLC® One LED Concept. Factory-installed LED circuit board. REMOTE DRIVER IN SEPARATE DRIVER BOX (CONSTANT CURRENT), PREWIRED; TO BE ORDERED SEPARATELY. Maximum one internal optical accessory possible, to be specified at time of ordering. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX – 9004 (Black) + XXX-XXXX (Accessory 1)

FLC201 LED Schematics
Colours
RAL9004 Black
RAL9007 Grey Metallic
RAL9016 White
RAL8019 Dark Bronze
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS Polymer Coated Stainless Steel Hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK07
Ingress ProtectionIP66
Corrosion Protection5CE
Electrical
Ballast / DriverRemote 120-277V , 0-10V (Dimming to be ordered separately)
Power Factor> 0.9
Additional Information
LifetimeTa=40° L90B10 > 90000h

Delivered Lumen

To
Part-IDLight DistributionLight SourceLumenCRISpecificationsPhotometrics
TextPDF
139-2435symmetric, wide beam [W]LED-1/6W / 500 mA - 2700 K518.480
139-2436symmetric, wide beam [W]LED-1/6W / 500 mA - 3000 K518.480
139-2437symmetric, wide beam [W]LED-1/6W / 500 mA - 4000 K557.180
139-2438symmetric, medium beam [M]LED-1/6W / 500 mA - 2700 K544.880
139-2439symmetric, medium beam [M]LED-1/6W / 500 mA - 3000 K544.880
139-2440symmetric, medium beam [M]LED-1/6W / 500 mA - 4000 K585.580
139-2441symmetric, narrow beam [N]LED-1/6W / 500 mA - 2700 K567.780
139-2442symmetric, narrow beam [N]LED-1/6W / 500 mA - 3000 K567.780
139-2443symmetric, narrow beam [N]LED-1/6W / 500 mA - 4000 K610.180
139-2444symmetric, very narrow beam [VN]LED-1/6W / 500 mA - 2700 K568.280
139-2445symmetric, very narrow beam [VN]LED-1/6W / 500 mA - 3000 K568.280
139-2446symmetric, very narrow beam [VN]LED-1/6W / 500 mA - 4000 K610.680
139-2447symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-1/6W / 500 mA - 2700 K516.680
139-2448symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-1/6W / 500 mA - 3000 K516.680
139-2449symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-1/6W / 500 mA - 4000 K558.680
Showing 1 to 15 of 15 Entries

Accessories

Part-IDTitlePDFOpen Data
139-6977FLC201 Remote Gear Box
ItemDownload
Product Images
Photometrics
Installation Instructions
WE-EF Brochure 2023 - FLC200 Series
