FLC230 LED

Back
Standard Colours
Tunable White
Family Spec Sheet
Standard Projector Standard Projector 75 mm 75 mm
Standard Projector Standard Projector 150 mm 150 mm
Standard Projector Standard Projector 190 mm 190 mm
Standard Projector Standard Projector 260 mm 260 mm
Standard Projector Standard Projector 340 mm 340 mm
Standard Projector Standard Projector 385 mm 385 mm

IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. One cable gland, second gland for through wiring on request. CAD-optimized optics for superior illumination and glare control. Integral driver, thermally separated. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming on request.
A maximum of one internal optical accessory. Optional 2200K version available, except [VNS] version, to be specified at time of order. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK07
SchutzartIP66
AbdeckungPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019
Korrosionsschutz5CE superior corrosion protection system
Befestigung

Elektrik

LED TreiberIntegral EC electronic converter in thermally-separated compartment
KabelOne cable entry, second cable entry on request. Request 0-10V to ensure control wires are connected.
Leistungsfaktor> 0.9
NetzIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
ÜberspannungsschutzIntegral 10kV Surge Protector

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h

Lichtverteilung

Lichtstrom (lm)

Leistung (W)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
139-1830symmetric, medium beam [M]LED-12/24W / 700 mA - 3000 K3152.380electronic gear16.80
139-1831symmetric, medium beam [M]LED-12/24W / 700 mA - 4000 K3369.780electronic gear16.80
139-1832symmetric, narrow beam [N]LED-12/24W / 700 mA - 3000 K2965.580electronic gear16.80
139-1833symmetric, narrow beam [N]LED-12/24W / 700 mA - 4000 K317080electronic gear16.80
139-1834symmetric, very narrow beam [VN]LED-12/24W / 700 mA - 3000 K3120.580electronic gear16.80
139-1835symmetric, very narrow beam [VN]LED-12/24W / 700 mA - 4000 K3335.780electronic gear16.80
139-1836symmetric, medium beam [M]LED-12/36W / 1050 mA - 3000 K4674.180electronic gear16.80
139-1839symmetric, narrow beam [N]LED-12/36W / 1050 mA - 4000 K4601.780electronic gear16.80
139-1837symmetric, medium beam [M]LED-12/36W / 1050 mA - 4000 K4891.580electronic gear16.80
139-1838symmetric, narrow beam [N]LED-12/36W / 1050 mA - 3000 K4397.180electronic gear16.80
139-1840symmetric, very narrow beam [VN]LED-12/36W / 1050 mA - 3000 K462780electronic gear16.80
139-1847symmetric, very narrow beam [VN]LED-12/52W / 1400 mA - 4000 K6063.780electronic gear16.80
139-1841symmetric, very narrow beam [VN]LED-12/36W / 1050 mA - 4000 K4842.280electronic gear16.80
139-1846symmetric, very narrow beam [VN]LED-12/52W / 1400 mA - 3000 K580080electronic gear16.80
139-1842symmetric, medium beam [M]LED-12/52W / 1400 mA - 3000 K5748.880electronic gear16.80
139-1843symmetric, medium beam [M]LED-12/52W / 1400 mA - 4000 K6010.180electronic gear16.80
139-1844symmetric, narrow beam [N]LED-12/52W / 1400 mA - 3000 K5412.280electronic gear16.80
139-1845symmetric, narrow beam [N]LED-12/52W / 1400 mA - 4000 K5658.280electronic gear16.80
139-1907symmetric, wide beam [W]LED-12/24W / 700 mA - 3000 K2990.780electronic gear16.80
139-1908symmetric, wide beam [W]LED-12/24W / 700 mA - 4000 K319780electronic gear16.80
139-1910symmetric, wide beam [W]LED-12/36W / 1050 mA - 4000 K4640.780electronic gear16.80
139-1911symmetric, wide beam [W]LED-12/52W / 1400 mA - 3000 K5480.480electronic gear16.80
139-1912symmetric, wide beam [W]LED-12/52W / 1400 mA - 4000 K5729.580electronic gear16.80
139-1909symmetric, wide beam [W]LED-12/36W / 1050 mA - 3000 K4434.580electronic gear16.80
139-1834linear spread, very narrow beam [VN]LED-12/24W / 700 mA - 3000 K2973.980electronic gear16.76
Showing 1 to 25 of 64 Entries
