ETC300 series

ETC320-FS LED

Static White
Colour Changer
Tunable White

Choose a variant:

Fixed
Gimbal

Choose a family:

D7.09" ⌀6.30" | ETC320-FS LED D7.87" ⌀9.84" | ETC330-FS LED D7.87" ⌀11.81" | ETC340-FS LED
Home
Products
Inground Luminaires
ETC320-FS LED
Family Spec Sheet Installation Instructions More Downloads

IP69K. Class I. IK10+. Stainless steel construction. PCS hardware. ASC Anti Slip ceramic Coating on request. Silicone CCG® Controlled Compression Gasket. Safety glass lens; max load 5.5 tons (11,000 lbs). Luminaire can be driven over at low speed. Factory-sealed termination chamber complete with cable gland and 3 ft of flexible PVC-free, gel-impregnated anti-wicking cable. CAD-optimized optics for superior illumination and glare control. Integral driver. Advanced thermal management protects LEDs while optimizing lumens output. LED module can be easily removed for upgrading. The concrete-pour installation blockout is supplied as standard with luminaire.

ETC320-FS LED Schematics
Colours
Stainless Steel
Material
BodyLuminaire body constructed of deep drawn stainless steel. Outer housing composite material.
FastenersPCS polymer coated stainless steel
GasketSilicone rubber gasket
Impact ProtectionIK10+
Ingress ProtectionIP69K - HIGHEST PROTECTION RATING AVAILABLE
FinishNatural stainless steel
Corrosion Protection5CE
MountingSuitable for installation in concrete or earth. Suitable for walk-over and drive-over applications. Proper drainage and foundation support must be provided.
Electrical
Ballast / DriverIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Cable3 feet of flexible 18/3 cable
Power SupplyIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Additional Information
LifetimeLED >60,000 h Ta 25°C (L70/B10) Control gear >50,000 h Ta 25°C
Dimming0-10V available in request. Must be factory fitted.

Delivered Lumen

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
185-7117symmetric, medium beam [M]LED-6/12W / 700 mA - 3000 K1531.880
185-7118symmetric, very narrow beam [VN]LED-6/12W / 700 mA - 3000 K149780
185-7120symmetric, medium beam [M]LED-6/12W / 700 mA - 4000 K1637.480
185-7121symmetric, very narrow beam [VN]LED-6/12W / 700 mA - 4000 K1600.380
185-7689symmetric, wide beam [W]LED-6/12W / 700 mA - 3000 K1363.580
185-7690symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-6/12W / 700 mA - 3000 K1624.780
185-7691symmetric, wide beam [W]LED-6/12W / 700 mA - 4000 K1457.580
185-7692symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-6/12W / 700 mA - 4000 K1736.880
185-7117wallwashLED-6/12W / 700 mA - 3000 K1179.480
185-7120wallwashLED-6/12W / 700 mA - 4000 K1260.880
185-7121linear spread, very narrow beam [VN]LED-6/12W / 700 mA - 4000 K1452.380
185-7690linear spread, very narrow beam, 'sharp cut-off'LED-6/12W / 700 mA - 3000 K1495.880
185-7692linear spread, very narrow beam, 'sharp cut-off'LED-6/12W / 700 mA - 4000 K1598.980
185-7118symmetric, narrow beam [N]LED-6/12W / 700 mA - 3000 K1386.380
185-7121symmetric, narrow beam [N]LED-6/12W / 700 mA - 4000 K1481.980
185-7690symmetric, narrow beam, 'sharp cut-off'LED-6/12W / 700 mA - 3000 K1510.780
185-7692symmetric, narrow beam, 'sharp cut-off'LED-6/12W / 700 mA - 4000 K1614.980
Showing 1 to 17 of 17 entries.
