ETC300 series

ETC320-FS LED

Static White
 Colour Changer
 Tunable White

Choose a variant:

Fixed
Gimbal

Choose a family:

ETC310-FS LED
Depth: 125 mm
Diameter ⌀: 120 mm
ETC319-FS LED
Depth: 125 mm
Diameter ⌀: 120 mm
ETC320-FS LED
Depth: 180 mm
Diameter ⌀: 160 mm
ETC329-FS LED
Depth: 180 mm
Diameter ⌀: 160 mm
ETC330-FS LED
Depth: 200 mm
Diameter ⌀: 250 mm
ETC339-FS LED
Depth: 200 mm
Diameter ⌀: 250 mm
ETC340-FS LED
Depth: 200 mm
Diameter ⌀: 300 mm
Home
Products
Inground Luminaires
ETC320-FS LED
Family Spec Sheet Installation Instructions More Downloads

IP69. IK10+. Stainless steel construction including PCS hardware. Safety glass lens; max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Anti-wick technology, equipped with a cable gland and 0.5 meters of flexible, PVC-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Luminaire installation blockout and sealable junction box included in supply.

ETC320-FS LED Schematics
Colours
Stainless Steel
Material
BodyStainless steel construction
FastenersPCS hardware
GasketSilicone rubber gasket
Impact ProtectionIK10+
Ingress ProtectionIP69
Finish-
MountingLuminaire installation blockout and sealable junction box included in supply
Electrical
Ballast / DriverIntegral EC electronic converter
CableComplete with cable gland and 0.5 m of flexible PVC-free cable
Additional Information

Delivered Lumen

To

Wattage

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
185-7117symmetric, medium beam [M]LED-6/12W / 700 mA - 3000 K1531.880 ULD
185-7118symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 3000 K149780 ULD
185-7120symmetric, medium beam [M]LED-6/12W / 700 mA - 4000 K1637.480 ULD
185-7121symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 4000 K1600.380 ULD
185-7689symmetric, wide beam [B]LED-6/12W / 700 mA - 3000 K1363.580 ULD
185-7690symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 3000 K1624.780 ULD
185-7691symmetric, wide beam [B]LED-6/12W / 700 mA - 4000 K1457.580 ULD
185-7692symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 4000 K1736.880 ULD
185-7117wallwashLED-6/12W / 700 mA - 3000 K1179.480 ULD
185-7120wallwashLED-6/12W / 700 mA - 4000 K1260.880 ULD
185-7118linear spread, very narrow beam [EE]LED-6/12W / 700 mA - 3000 K1358.680 ULD
185-7121linear spread, very narrow beam [EE]LED-6/12W / 700 mA - 4000 K1452.380 ULD
185-7690linear spread, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 3000 K1495.880 ULD
185-7692linear spread, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 4000 K1598.980 ULD
185-7118flood, very narrow beam [EE]LED-6/12W / 700 mA - 3000 K1386.380 ULD
185-7121flood, very narrow beam [EE]LED-6/12W / 700 mA - 4000 K1481.980 ULD
185-7690flood, narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 3000 K1510.780 ULD
185-7692flood, narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 4000 K1614.980 ULD
185-7271symmetric, wide beam [B]LED-6/12W / 700 mA - 2700 K109680
185-7272symmetric, medium beam [M]LED-6/12W / 700 mA - 2700 K1230.280
185-7273symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 2700 K1202.380
185-7274symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 2700 K1305.780
185-7273linear spread, very narrow beam [EE]LED-6/12W / 700 mA - 2700 K1091.880
185-7274linear spread, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 2700 K1202.380
185-7272wallwashLED-6/12W / 700 mA - 2700 K947.880
185-7273flood, very narrow beam [EE]LED-6/12W / 700 mA - 2700 K1114.280
185-7274flood, narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 2700 K1213.580
Showing 1 to 27 of 27 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
on requestColour filter IF
