ETC300 series

ETC330-FS LED

Static White Colour Changer Tunable White

Choose a variant:

Fixed

Gimbal

Choose a family:

D7.09" ⌀6.30" | ETC320-FS LED D7.87" ⌀9.84" | ETC330-FS LED D7.87" ⌀11.81" | ETC340-FS LED

Family Spec Sheet Installation Instructions More Downloads

IP69K. Class I. IK10+. Stainless steel construction. PCS hardware. ASC Anti Slip ceramic Coating on request. Silicone CCG® Controlled Compression Gasket. Safety glass lens; max load 5.5 tons (11,000 lbs). Luminaire can be driven over at low speed. Factory-sealed termination chamber complete with cable gland and 3 ft of flexible PVC-free, gel-impregnated anti-wicking cable. CAD-optimized optics for superior illumination and glare control. Integral driver. Advanced thermal management protects LEDs while optimizing lumens output. LED module can be easily removed for upgrading. The concrete-pour installation blockout is supplied as standard with luminaire.

Colours

Stainless Steel

Material

Body	Luminaire body constructed of deep drawn stainless steel. Outer housing composite material.
Fasteners	PCS polymer coated stainless steel
Impact Protection	IK10+
Ingress Protection	IP69K - HIGHEST PROTECTION RATING AVAILABLE
Finish	Natural stainless steel
Corrosion Protection	5CE
Mounting	Suitable for installation in concrete or earth. Suitable for walk-over and drive-over applications. Proper drainage and foundation support must be provided.

Electrical

Ballast / Driver	Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Cable	3 feet of flexible 18/3 cable
Power Supply	Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.

Additional Information

Lifetime	LED >60,000 h Ta 25°C (L70/B10) Control gear >50,000 h Ta 25°C
Dimming	0-10V available in request. Must be factory fitted.

Light Distribution

Delivered Lumen

Wattage

Colour Temperature

Part-ID	Light Distribution	Light Source	Delivered Lumen	CRI	Specifications
					Text	PDF
185-7032	symmetric, very narrow beam [VN]	LED-12/24W / 700 mA - 3000 K	2850.7	80
185-7033	symmetric, medium beam [M]	LED-12/24W / 700 mA - 3000 K	3019.6	80
185-7036	symmetric, very narrow beam [VN]	LED-12/24W / 700 mA - 4000 K	3047.3	80
185-7037	symmetric, medium beam [M]	LED-12/24W / 700 mA - 4000 K	3227.8	80
185-7693	symmetric, wide beam [W]	LED-12/24W / 700 mA - 3000 K	2631	80
185-7694	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-12/24W / 700 mA - 3000 K	3033.1	80
185-7695	symmetric, wide beam [W]	LED-12/24W / 700 mA - 4000 K	2812.4	80
185-7696	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-12/24W / 700 mA - 4000 K	3242.2	80
185-7033	wallwash	LED-12/24W / 700 mA - 3000 K	2431.6	80
185-7037	wallwash	LED-12/24W / 700 mA - 4000 K	2599.3	80
185-7032	linear spread, very narrow beam [VN]	LED-12/24W / 700 mA - 3000 K	2662	80
185-7036	linear spread, very narrow beam [VN]	LED-12/24W / 700 mA - 4000 K	2845.5	80
185-7036	symmetric, narrow beam [N]	LED-12/24W / 700 mA - 4000 K	2857.9	80
185-7694	linear spread, very narrow beam, 'sharp cut-off'	LED-12/24W / 700 mA - 3000 K	2779.9	80
185-7032	symmetric, narrow beam [N]	LED-12/24W / 700 mA - 3000 K	2673.6	80
185-7694	symmetric, narrow beam, 'sharp cut-off'	LED-12/24W / 700 mA - 3000 K	2864.5	80
185-7696	linear spread, very narrow beam, 'sharp cut-off'	LED-12/24W / 700 mA - 4000 K	2971.7	80
185-7696	symmetric, narrow beam, 'sharp cut-off'	LED-12/24W / 700 mA - 4000 K	3062	80
185-7276	symmetric, wide beam [W]	LED-12/24W / 700 mA - 2700 K	2113.8	80
185-7277	symmetric, medium beam [M]	LED-12/24W / 700 mA - 2700 K	2426.9	80
185-7278	symmetric, very narrow beam [VN]	LED-12/24W / 700 mA - 2700 K	2289.9	80
185-7279	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-12/24W / 700 mA - 2700 K	2438.1	80
185-7277	wallwash	LED-12/24W / 700 mA - 2700 K	1954.4	80
185-7278	linear spread, very narrow beam [VN]	LED-12/24W / 700 mA - 2700 K	2138.9	80
185-7278	symmetric, narrow beam [N]	LED-12/24W / 700 mA - 2700 K	2147.3	80
185-7279	linear spread, very narrow beam, 'sharp cut-off'	LED-12/24W / 700 mA - 2700 K	2234	80
185-7279	symmetric, narrow beam, 'sharp cut-off'	LED-12/24W / 700 mA - 2700 K	2301.1	80

Showing 1 to 27 of 27 entries.
