DOC220 LED

Back
Standard Colours
Dark Light
Dark Light & Tunable White
Family Spec Sheet
96 mm 96 mm 117 mm 117 mm
96 mm 96 mm 155 mm 155 mm
96 mm 96 mm 216 mm 216 mm
101 mm 101 mm 154 mm 154 mm
102 mm 102 mm 250 mm 250 mm

IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens, hinged. Two cable entries. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Frame with safety catch.
Suitable for installation in non-insulated ceiling. A pre-installation blockout, proud or flush, is available and recommended for mounting in concrete ceilings; to be ordered separately. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Eigenschaften

Material

GehäuseLuminaire body and lens frame constructed in die cast aluminum.
SchraubenPCS polymer coated stainless steel
FarbenPending
DichtungSilicone rubber gasket
SchlagfestigkeitIK07
SchutzartIP66
AbdeckungPowder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019.
Korrosionsschutz5CE
BefestigungSuitable for installation in non-insulated ceiling, using galvanized mounting tray and hanger bars. Maximum ceiling thickness 1.5 in.

Elektrik

LED TreiberIntegral EC electronic converter in thermally-separated compartment
KabelTwo cable entries
Leistungsfaktor
NetzIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Überspannungsschutz

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
134-1210symmetric, medium beam [M]LED-12/24W / 700 mA - 3000 K2998.680electronic gear6.40
134-1211symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-12/24W / 700 mA - 3000 K3077.980electronic gear6.40
134-1211linear spread, very narrow beam, 'sharp cut-off'LED-12/24W / 700 mA - 3000 K2865.980electronic gear6.40
134-1212symmetric, medium beam [M]LED-12/24W / 700 mA - 4000 K3205.480electronic gear6.40
134-1213symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-12/24W / 700 mA - 4000 K3290.280electronic gear6.40
134-1213linear spread, very narrow beam, 'sharp cut-off'LED-12/24W / 700 mA - 4000 K3063.580electronic gear6.40
134-1332symmetric, wide beam [W]LED-12/24W / 700 mA - 3000 K2709.280electronic gear6.40
134-1333symmetric, wide beam [W]LED-12/24W / 700 mA - 4000 K289680electronic gear6.40
134-1335symmetric, very narrow beam [VN]LED-12/24W / 700 mA - 3000 K2883.780electronic gear6.40
134-1335linear spread, very narrow beamLED-12/24W / 700 mA - 3000 K2744.280electronic gear6.40
134-1336symmetric, very narrow beam [VN]LED-12/24W / 700 mA - 4000 K3082.580electronic gear6.40
134-1336linear spread, very narrow beamLED-12/24W / 700 mA - 4000 K2933.480electronic gear6.40
134-1212wallwash [A20]LED-12/24W / 700 mA - 4000 K2571.580electronic gear6.40
134-1210wallwash [A20]LED-12/24W / 700 mA - 3000 K2405.680electronic gear6.40
134-1210linear spread, medium beam [M]LED-12/24W / 700 mA - 3000 K2944.880electronic gear6.40
134-1212linear spread, medium beam [M]LED-12/24W / 700 mA - 4000 K3147.980electronic gear6.40
Showing 1 to 16 of 16 Entries
