DOC220 LED

Back
Standard Colours
Dark Light
Dark Light & Tunable White
Family Spec Sheet
96 mm 96 mm 117 mm 117 mm
96 mm 96 mm 155 mm 155 mm
96 mm 96 mm 216 mm 216 mm
101 mm 101 mm 154 mm 154 mm
102 mm 102 mm 250 mm 250 mm

IP66, Class I. Class II on request. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone rubber gasket. Safety glass lens, hinged. Frame with safety catch. Two cable entries. Integral EC electronic converter in thermally separated compartment. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board.
Optional 2200 K version available. To be specified at time of ordering. A pre-installation blockout, proud or flush, is available and recommended for mounting in concrete ceilings. To be ordered separately. Luminaire suitable for chlorine containing environments e.g. swimming pools, on request. Must be specified at time of ordering.

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone rubber gasket
SchlagfestigkeitIK07
SchutzartIP66
AbdeckungPowdercoat finish in RAL7016, RAL9004, RAL9006, RAL9007 and RAL9016
Korrosionsschutz5CE
BefestigungPre-installation blockout is recommended for mounting in cast concrete ceilings, available on request.

Elektrik

LED TreiberStandard. Optional DALI version available. To be specified at time of ordering.
KabelTwo cable entries
Leistungsfaktor
Netz220-240V / 50-60 Hz
Überspannungsschutz6/6 kV

Weitere Eigenschaften

LifetimeTa=25° L90B10 > 90000h
Energy efficiency classC-D (Light source)

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
134-1210symmetric, medium beam [M]LED-12/24W / 700 mA - 3000 K2998.680EC2.10
134-1211symmetric, very narrow beam, sharp cut-off [EES]LED-12/24W / 700 mA - 3000 K3077.980EC2.10
134-1211linear spread, very narrow beam, sharp cut-off [EES]LED-12/24W / 700 mA - 3000 K2865.980EC2.10
134-1212symmetric, medium beam [M]LED-12/24W / 700 mA - 4000 K3205.480EC2.10
134-1213symmetric, very narrow beam, sharp cut-off [EES]LED-12/24W / 700 mA - 4000 K3290.280EC2.10
134-1213linear spread, very narrow beam, sharp cut-off [EES]LED-12/24W / 700 mA - 4000 K3063.580EC2.10
134-1332symmetric, wide beam [B]LED-12/24W / 700 mA - 3000 K2709.280EC2.10
134-1333symmetric, wide beam [B]LED-12/24W / 700 mA - 4000 K289680EC2.10
134-1335symmetric, very narrow beam [EE]LED-12/24W / 700 mA - 3000 K2883.780EC2.10
134-1335linear spread, very narrow beam [EE]LED-12/24W / 700 mA - 3000 K2744.280EC2.10
134-1336symmetric, very narrow beam [EE]LED-12/24W / 700 mA - 4000 K3082.580EC2.10
134-1336linear spread, very narrow beam [EE]LED-12/24W / 700 mA - 4000 K2933.480EC2.10
134-1212wallwash [A20]LED-12/24W / 700 mA - 4000 K2571.580EC2.10
134-1210wallwash [A20]LED-12/24W / 700 mA - 3000 K2405.680EC2.10
134-1931symmetric, wide beam [B]LED-12/24W / 700 mA - 2700 K2522.380EC2.10
134-1932symmetric, medium beam [M]LED-12/24W / 700 mA - 2700 K2791.880EC2.10
134-1933symmetric, very narrow beam [EE]LED-12/24W / 700 mA - 2700 K2684.880EC2.10
134-1934symmetric, very narrow beam, sharp cut-off [EES]LED-12/24W / 700 mA - 2700 K2865.680EC2.10
Showing 1 to 18 of 18 Entries
