DOR100 series

DOR120 LED

Static White

Choose a family:

D90 ⌀140 mm | DOR120 LED D100 ⌀175 mm | DOR130 LED D125 ⌀250 mm | DOR140 LED
Home
Products
Ceiling Luminaires
DOR120 LED
Family Spec Sheet Installation Instructions More Downloads

IP66. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection + primer including PCS hardware. PMMA lens (DOR120) or safety glass lens (DOR130/DOR140). Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. Two cable entries. Pre-installation blockout is recommended for mounting in cast concrete ceilings available on request. 1-10 V analogue dimming or DALI interface (where applicable) available on request. 2700 K option available on request.

DOR120 LED Schematics
Colours
RAL9004 Signal black
RAL9006 White aluminium
RAL9007 Grey aluminium
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS Polymer Coated Stainless Steel Hardware (unpainted)
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK08
Ingress ProtectionIP66
FinishPowdercoat finish in black RAL9004, grey aluminium RAL9007, white aluminium RAL9006 or white RAL9016
Corrosion Protection5CE+Primer
MountingPre-installation blockout is recommended for mounting in cast concrete ceilings, available on request
Electrical
Ballast / DriverEC electronic converter in thermally-separated compartment
Cable2.0m flex and plug
Power Supply230V / 50 Hz
Additional Information
LifetimeTa=40° L90B10 > 90000h
WarrantyThe product is supplied with 10-year warranty. Please refer to the LED Warranty Statement located on www.we-ef.com for further details.

Delivered Lumen

To

Wattage

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
135-9003symmetric, medium beam [M]LED-6/12W / 700 mA - 3000 K1454.180
135-9004symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 3000 K1393.480
135-9006symmetric, medium beam [M]LED-6/12W / 700 mA - 4000 K1554.380
135-9007symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 4000 K1489.580
135-9008symmetric, wide beam [B]LED-6/12W / 700 mA - 3000 K1148.380
135-9009symmetric, wide beam [B]LED-6/12W / 700 mA - 4000 K1227.580
135-9010symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 3000 K1492.980
135-9011symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 4000 K1595.980
135-9016symmetric, wide beam [B]LED-6/18W / 1050 mA - 3000 K2018.880
135-9019symmetric, wide beam [B]LED-6/18W / 1050 mA - 4000 K2112.780
135-9017symmetric, medium beam [M]LED-6/18W / 1050 mA - 3000 K2167.280
135-9020symmetric, medium beam [M]LED-6/18W / 1050 mA - 4000 K226880
135-9018symmetric, very narrow beam [EE]LED-6/18W / 1050 mA - 3000 K2165.680
135-9021symmetric, very narrow beam [EE]LED-6/18W / 1050 mA - 4000 K2266.480
