DOR120 LED
Depth: 90 mm
Diameter ⌀: 140 mm
DOR130 LED
Depth: 100 mm
Diameter ⌀: 175 mm
DOR140 LED
Depth: 125 mm
Diameter ⌀: 250 mm
Home
Products
Ceiling Luminaires
DOR120 LED
Family Spec Sheet Installation Instructions More Downloads

IP66. IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Two cable entries. Pre-installation blockout is recommended for mounting in cast concrete ceilings, available on request.

DOR120 LED Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK08
Ingress ProtectionIP66
FinishPowdercoat finish in RAL9004, RAL9006, RAL9007, RAL7016 and RAL9016
Corrosion Protection5CE
MountingPre-installation blockout is recommended for mounting in cast concrete ceilings, available on request
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-separated compartment
CableTwo cable entries
Additional Information

Delivered Lumen

To

Wattage

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
135-9003symmetric, medium beam [M]LED-6/12W / 700 mA - 3000 K1454.180 ULD
135-9004symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 3000 K1393.480 ULD
135-9006symmetric, medium beam [M]LED-6/12W / 700 mA - 4000 K1554.380 ULD
135-9007symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 4000 K1489.580 ULD
135-9008symmetric, wide beam [B]LED-6/12W / 700 mA - 3000 K1148.380 ULD
135-9009symmetric, wide beam [B]LED-6/12W / 700 mA - 4000 K1227.580 ULD
135-9010symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 3000 K1492.980 ULD
135-9011symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 4000 K1595.980 ULD
135-9016symmetric, wide beam [B]LED-6/18W / 1050 mA - 3000 K2018.880 ULD
135-9019symmetric, wide beam [B]LED-6/18W / 1050 mA - 4000 K2112.780 ULD
135-9017symmetric, medium beam [M]LED-6/18W / 1050 mA - 3000 K2167.280 ULD
135-9020symmetric, medium beam [M]LED-6/18W / 1050 mA - 4000 K226880 ULD
135-9018symmetric, very narrow beam [EE]LED-6/18W / 1050 mA - 3000 K2165.680 ULD
135-9021symmetric, very narrow beam [EE]LED-6/18W / 1050 mA - 4000 K2266.480 ULD
135-9026symmetric, wide beam [B]LED-6/12W / 700 mA - 2700 K1069.180 ULD
135-9076symmetric, wide beam [B]LED-6/18W / 1050 mA - 2700 K1924.980 ULD
135-9023symmetric, medium beam [M]LED-6/12W / 700 mA - 2700 K1353.880 ULD
135-9077symmetric, medium beam [M]LED-6/18W / 1050 mA - 2700 K2066.480 ULD
135-9024symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 2700 K1297.380 ULD
135-9078symmetric, very narrow beam [EE]LED-6/18W / 1050 mA - 2700 K2064.980 ULD
135-9025symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 2700 K139080 ULD
