IP66. IK08. Marine-grade, all aluminium construction. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. Two cable entries.
12W, 18W, 26W / 120-277V / 0-10V Dimming.
24VDC low voltage versions, ON-OFF. (available upon request)
Knuckle permits 340° rotation, forward tilt 54° and backward tilt 90°.
Remote 24VDC power supply to be ordered separately.
Optical accessories are factory-installed. To be specified at time of ordering.
Eigenschaften
Material
Gehäuse
Marine-grade, all aluminium construction
Schrauben
PCS hardware
Farben
Pending
Dichtung
Silicone CCG® Controlled Compression Gasket
Schlagfestigkeit
IK08
Schutzart
IP66
Abdeckung
Korrosionsschutz
5CE
Befestigung
Elektrik
LED Treiber
120-277V AC/50-60 Hz (24VDC available upon request)
Kabel
Two cable entries
Leistungsfaktor
Netz
Überspannungsschutz
Weitere Eigenschaften
Lifetime
Ta=25°/40° L90B10 > 90000h
----
Lichtverteilung
Lichtstrom (lm)
Farbtemperatur (K)
Artikelnummer
Lichtverteilung
Lichtquelle
Bemessungslichtstrom
CRI
Vorschaltgerät
Gewicht (kg)
Open Data (txt)
Datenblatt
IES, LDT, ULD
145-7900
symmetric, wide beam [W]
LED-6/12W / 700 mA - 2700 K
887.8
80
electronic gear
9.00
145-7902
symmetric, wide beam [W]
LED-6/12W / 700 mA - 3000 K
953.5
80
electronic gear
9.00
145-7904
symmetric, wide beam [W]
LED-6/12W / 700 mA - 4000 K
1019.3
80
electronic gear
9.00
145-7906
symmetric, medium beam [M]
LED-6/12W / 700 mA - 2700 K
1162.6
80
electronic gear
9.00
145-7908
symmetric, medium beam [M]
LED-6/12W / 700 mA - 3000 K
1248.7
80
electronic gear
9.00
145-7910
symmetric, medium beam [M]
LED-6/12W / 700 mA - 4000 K
1334.9
80
electronic gear
9.00
145-7912
symmetric, very narrow beam [VN]
LED-6/12W / 700 mA - 2700 K
1224.7
80
electronic gear
5.70
145-7914
symmetric, very narrow beam [VN]
LED-6/12W / 700 mA - 3000 K
1315.4
80
electronic gear
5.70
145-7916
symmetric, very narrow beam [VN]
LED-6/12W / 700 mA - 4000 K
1406.2
80
electronic gear
5.70
145-7918
symmetric, very narrow beam, 'sharp cut-off' [VNS]
LED-6/12W / 700 mA - 2700 K
1259.7
80
electronic gear
5.70
145-7920
symmetric, very narrow beam, 'sharp cut-off' [VNS]
LED-6/12W / 700 mA - 3000 K
1353
80
electronic gear
5.70
145-7922
symmetric, very narrow beam, 'sharp cut-off' [VNS]
LED-6/12W / 700 mA - 4000 K
1446.3
80
electronic gear
5.70
145-7901
symmetric, wide beam [W]
LED-6/18W / 1050 mA - 2700 K
1233
80
electronic gear
9.00
145-7903
symmetric, wide beam [W]
LED-6/18W / 1050 mA - 3000 K
1331.7
80
electronic gear
9.00
145-7905
symmetric, wide beam [W]
LED-6/18W / 1050 mA - 4000 K
1413.9
80
electronic gear
9.00
145-7907
symmetric, medium beam [M]
LED-6/18W / 1050 mA - 2700 K
1614.8
80
electronic gear
9.00
145-7909
symmetric, medium beam [M]
LED-6/18W / 1050 mA - 3000 K
1743.9
80
electronic gear
9.00
145-7911
symmetric, medium beam [M]
LED-6/18W / 1050 mA - 4000 K
1851.6
80
electronic gear
9.00
145-7913
symmetric, very narrow beam [VN]
LED-6/18W / 1050 mA - 2700 K
1701
80
electronic gear
9.00
145-7915
symmetric, very narrow beam [VN]
LED-6/18W / 1050 mA - 3000 K
1837.1
80
electronic gear
9.00
145-7917
symmetric, very narrow beam [VN]
LED-6/18W / 1050 mA - 4000 K
1950.5
80
electronic gear
9.00
145-7919
symmetric, very narrow beam, 'sharp cut-off' [VNS]
LED-6/18W / 1050 mA - 2700 K
1749.6
80
electronic gear
9.00
145-7921
symmetric, very narrow beam, 'sharp cut-off' [VNS]
LED-6/18W / 1050 mA - 3000 K
1889.5
80
electronic gear
9.00
145-7923
symmetric, very narrow beam, 'sharp cut-off' [VNS]
