FLC300

Wallbracket Spigot Mounted Surface Mounted

58 mm

FLC301

FLC301 Spigot mounted

Family Spec Sheet

IP66. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. Including 5 ft of flexible PVC free cable. Optical accessories are factory-installed. To be specified at time of ordering. 4W / 120V mains voltage version, ON-OFF Class I. Non-dimming. 6W / 24V DC low voltage version available upon request, ON-OFF Class III. Non-dimming. Dimmable versions can only be done with a remote driver (120-277V) 347V remote driver on request.

Colors

RAL9004 Black

RAL9006 White

RAL9007 Grey Metallic

RAL7016 Anthracite grey

RAL9016 White

RAL8019 Dark Bronze

Powdercoat finish available in 35 different colours

Material

Body	Marine-grade, die-cast aluminium alloy
Fasteners	PCS hardware
Gasket	Silicone CCG® Controlled Compression Gasket
Impact Protection	IK07
Ingress Protection	IP66
Finish
Corrosion Protection	5CE
Mounting	Slipfitter suitable for mounting accessories

Electrical

Ballast / Driver	Integral EC electronic converter (ON/OFF only)
Cable	Including 5 ft of flexible PVC free cable
Power Factor	>0.9
Power Supply	120V AC/50-60 Hz (24V DC available upon request)
Surge Protection

Additional Information

Lifetime	Ta=25°/40° L90B10 > 90000h
Dimming	0-10V Dimming with Remote Driver only

Light Distribution

Delivered Lumen

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
145-7180	symmetric, wide beam [W]	LED-1/4W / 350 mA – 2700 K	379.1	80
145-7181	symmetric, wide beam [W]	LED-1/4W / 350 mA – 3000 K	379.1	80
145-7182	symmetric, wide beam [W]	LED-1/4W / 350 mA – 4000 K	410.1	80
145-7183	symmetric, medium beam [M]	LED-1/4W / 350 mA – 2700 K	398.4	80
145-7184	symmetric, medium beam [M]	LED-1/4W / 350 mA – 3000 K	398.4	80
145-7185	symmetric, medium beam [M]	LED-1/4W / 350 mA – 4000 K	431	80
145-7240	symmetric, narrow beam [N]	LED-1/4W / 350 mA – 2700 K	415.2	80
145-7241	symmetric, narrow beam [N]	LED-1/4W / 350 mA – 3000 K	415.2	80
145-7242	symmetric, narrow beam [N]	LED-1/4W / 350 mA – 4000 K	449.1	80
145-7186	symmetric, very narrow beam [VN]	LED-1/4W / 350 mA – 2700 K	415.5	80
145-7187	symmetric, very narrow beam [VN]	LED-1/4W / 350 mA – 3000 K	415.5	80
145-7188	symmetric, very narrow beam [VN]	LED-1/4W / 350 mA – 4000 K	449.5	80
145-7189	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-1/4W / 350 mA – 2700 K	382.2	80
145-7190	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-1/4W / 350 mA – 3000 K	382.2	80
145-7191	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-1/4W / 350 mA – 4000 K	411.6	80
145-7186	linear spread, very narrow beam [VN]	LED-1/4W / 350 mA – 2700 K	384.7	80
145-7187	linear spread, very narrow beam [VN]	LED-1/4W / 350 mA – 3000 K	384.7	80
145-7188	linear spread, very narrow beam [VN]	LED-1/4W / 350 mA – 4000 K	416.1	80
145-7189	linear spread, very narrow beam, 'sharp cut-off'	LED-1/4W / 350 mA – 2700 K	343.5	80
145-7190	linear spread, very narrow beam, 'sharp cut-off'	LED-1/4W / 350 mA – 3000 K	343.5	80
145-7191	linear spread, very narrow beam, 'sharp cut-off'	LED-1/4W / 350 mA – 4000 K	369.9	80
145-7183	wallwash	LED-1/4W / 350 mA – 2700 K	358.8	80
145-7184	wallwash	LED-1/4W / 350 mA – 3000 K	331.7	80
145-7185	wallwash	LED-1/4W / 350 mA – 4000 K	358.8	80
