FLC300

Wallbracket Spigot Mounted Surface Mounted

58 mm

FCL301

FLC301 Surface mounted

Family Spec Sheet

IP66. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. Optical accessories are factory-installed. To be specified at time of ordering. 4W / 120V mains voltage version, ON-OFF Class I. Non-dimming. 6W / 24V DC low voltage version available upon request, ON-OFF Class III. Non-dimming. Dimmable version can only be done with a remote driver (120-277V) 347V remote driver on request.

Colors

RAL9004 Black

RAL9006 White

RAL9007 Grey Metallic

RAL7016 Anthracite grey

RAL9016 White

RAL8019 Dark Bronze

Powdercoat finish available in 35 different colours

Material

Body	Marine-grade, die-cast aluminium alloy
Fasteners	PCS hardware
Gasket	Silicone CCG® Controlled Compression Gasket
Impact Protection	IK07
Ingress Protection	IP66
Finish
Corrosion Protection	5CE
Mounting

Electrical

Ballast / Driver	Integral EC electronic converter (ON/OFF only)
Cable
Power Factor	>0.9
Power Supply	120V AC/50-60 Hz (24V DC available upon request)
Surge Protection

Additional Information

Lifetime	Ta=25°/40° L90B10 > 90000h
Dimming	0-10V Dimming with Remote Driver only

Light Distribution

Delivered Lumen

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
145-7192	symmetric, wide beam [W]	LED-1/4W / 350 mA – 2700 K	379.1	80
145-7193	symmetric, wide beam [W]	LED-1/4W / 350 mA – 3000 K	379.1	80
145-7194	symmetric, wide beam [W]	LED-1/4W / 350 mA – 4000 K	410.1	80
145-7195	symmetric, medium beam [M]	LED-1/4W / 350 mA – 2700 K	398.4	80
145-7196	symmetric, medium beam [M]	LED-1/4W / 350 mA – 3000 K	398.4	80
145-7197	symmetric, medium beam [M]	LED-1/4W / 350 mA – 4000 K	431	80
145-7243	symmetric, narrow beam [N]	LED-1/4W / 350 mA – 2700 K	415.2	80
145-7244	symmetric, narrow beam [N]	LED-1/4W / 350 mA – 3000 K	415.2	80
145-7245	symmetric, narrow beam [N]	LED-1/4W / 350 mA – 4000 K	449.1	80
145-7198	symmetric, very narrow beam [VN]	LED-1/4W / 350 mA – 2700 K	415.5	80
145-7199	symmetric, very narrow beam [VN]	LED-1/4W / 350 mA – 3000 K	415.5	80
145-7200	symmetric, very narrow beam [VN]	LED-1/4W / 350 mA – 4000 K	449.5	80
145-7201	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-1/4W / 350 mA – 2700 K	382.2	80
145-7202	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-1/4W / 350 mA – 3000 K	382.2	80
145-7203	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-1/4W / 350 mA – 4000 K	411.6	80
145-7198	linear spread, very narrow beam [VN]	LED-1/4W / 350 mA – 2700 K	384.7	80
145-7199	linear spread, very narrow beam [VN]	LED-1/4W / 350 mA – 3000 K	384.7	80
145-7200	linear spread, very narrow beam [VN]	LED-1/4W / 350 mA – 4000 K	416.1	80
145-7201	linear spread, very narrow beam, 'sharp cut-off'	LED-1/4W / 350 mA – 2700 K	343.5	80
145-7202	linear spread, very narrow beam, 'sharp cut-off'	LED-1/4W / 350 mA – 3000 K	343.5	80
145-7203	linear spread, very narrow beam, 'sharp cut-off'	LED-1/4W / 350 mA – 4000 K	369.9	80
145-7195	wallwash	LED-1/4W / 350 mA – 2700 K	331.7	80
145-7196	wallwash	LED-1/4W / 350 mA – 3000 K	331.7	80
145-7197	wallwash	LED-1/4W / 350 mA – 4000 K	358.8	80
