FLC301 Wall bracket

Back
Wallbracket
Spigot Mounted
Surface Mounted
Family Spec Sheet
Standard Projector Standard Projector 112 mm 112 mm
Standard Projector Standard Projector 115 mm 115 mm
Standard Projector Standard Projector 193 mm 193 mm
Micro Projector Micro Projector 58 mm 58 mm
Micro Projector Micro Projector 85 mm 85 mm
Micro Projector Micro Projector 115 mm 115 mm

IP66. IK07. Marine-grade, all aluminium construction. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation.
Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. Two cable entries. Mains voltage versions, ON-OFF Class I. Integral EC electronic converter. 24VDC low voltage versions available upon request, ON-OFF Class III. Knuckle permits 340° rotation, forward tilt 73° and backward tilt 90°. Remote 24VDC power supply to be ordered separately.

Eigenschaften

Material

GehäuseMarine-grade, all aluminium construction
SchraubenPCS hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK07
SchutzartIP66
Abdeckung
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberIntegral EC electronic converter
KabelTwo cable entries
Leistungsfaktor
Netz120V AC/50-60 Hz (24V DC available upon request)
Überspannungsschutz

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
145-7204symmetric, wide beam [W]LED-1/4W / 350 mA – 2700 K379.180electronic gear2.30
145-7205symmetric, wide beam [W]LED-1/4W / 350 mA – 3000 K379.180electronic gear2.30
145-7206symmetric, wide beam [W]LED-1/4W / 350 mA – 4000 K410.180electronic gear2.30
145-7207symmetric, medium beam [M]LED-1/4W / 350 mA – 2700 K398.480electronic gear2.30
145-7208symmetric, medium beam [M]LED-1/4W / 350 mA – 3000 K398.480electronic gear2.30
145-7209symmetric, medium beam [M]LED-1/4W / 350 mA – 4000 K43180electronic gear2.30
145-7246symmetric, narrow beam [N]LED-1/4W / 350 mA – 2700 K415.280electronic gear2.30
145-7247symmetric, narrow beam [N]LED-1/4W / 350 mA – 3000 K415.280electronic gear2.30
145-7248symmetric, narrow beam [N]LED-1/4W / 350 mA – 4000 K449.180electronic gear2.30
145-7210symmetric, very narrow beam [VN]LED-1/4W / 350 mA – 2700 K415.580electronic gear2.30
145-7211symmetric, very narrow beam [VN]LED-1/4W / 350 mA – 3000 K415.580electronic gear2.30
145-7212symmetric, very narrow beam [VN]LED-1/4W / 350 mA – 4000 K449.580electronic gear2.30
145-7213symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-1/4W / 350 mA – 2700 K382.280electronic gear2.30
145-7214symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-1/4W / 350 mA – 3000 K382.280electronic gear2.30
145-7215symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-1/4W / 350 mA – 4000 K411.680electronic gear2.30
145-7210linear spread, very narrow beam [VN]LED-1/4W / 350 mA – 2700 K384.780electronic gear2.30
145-7211linear spread, very narrow beam [VN]LED-1/4W / 350 mA – 3000 K384.780electronic gear2.30
145-7212linear spread, very narrow beam [VN]LED-1/4W / 350 mA – 4000 K416.180electronic gear2.30
145-7213linear spread, very narrow beam, 'sharp cut-off'LED-1/4W / 350 mA – 2700 K343.580electronic gear2.30
145-7214linear spread, very narrow beam, 'sharp cut-off'LED-1/4W / 350 mA – 3000 K343.580electronic gear2.30
145-7215linear spread, very narrow beam, 'sharp cut-off'LED-1/4W / 350 mA – 4000 K369.980electronic gear2.30
145-7207wallwashLED-1/4W / 350 mA – 2700 K331.780electronic gear2.30
145-7208wallwashLED-1/4W / 350 mA – 3000 K331.780electronic gear2.30
145-7209wallwashLED-1/4W / 350 mA – 4000 K358.880electronic gear2.30
Showing 1 to 24 of 24 Entries
