FLC300 series

FLC311 Wall bracket

Static White

Choose a variant:

Spigot-Mounted

Surface-Mounted

Wallbracket

Choose a family:

⌀2.28" | FLC301 Wall bracket ⌀3.35" | FLC311 Wall bracket ⌀4.53" | FLC321 Wall bracket

Family Spec Sheet Installation Instructions More Downloads

IP66. IK08. Marine-grade, all aluminium construction. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. Two cable entries. Mains voltage versions, ON-OFF Class I. 1-10 V analogue dimming or DALI interface available on request; refer to accessory listings. 24VDC low voltage versions, 0-10 V Class III. (available upon request) Knuckle permits 340° rotation, forward tilt 54° and backward tilt 90°. Remote 24VDC power supply to be ordered separately.

Colours

RAL9004 Black

RAL9007 Grey Metallic

RAL9016 White

Material

Body	Marine-grade, all aluminium construction
Fasteners	PCS hardware
Gasket	Silicone CCG® Controlled Compression Gasket
Impact Protection	IK08
Ingress Protection	IP66
Corrosion Protection	5CE
Mounting	Knuckle permits 340° rotation, forward tilt 54° and backward tilt 90°

Electrical

Ballast / Driver	Integral [ECG] electronic driver 120V-277V. (24VDC low voltage, available upon request)
Cable	Two cable entries
Power Supply	120-277VAC/50-60 Hz (24V DC available upon request)

Additional Information

Lifetime

Ta=25°/40° L90B10 > 90000h

Light Distribution

Delivered Lumen

Colour Temperature

Part-ID	Light Distribution	Light Source	Delivered Lumen	CRI	Specifications
					Text	PDF
145-7672	symmetric, wide beam [W]	LED-3/6W / 180 mA - 2700 K	595.4	80
145-7675	symmetric, wide beam [W]	LED-3/6W / 180 mA - 3000 K	595.4	80
145-7678	symmetric, wide beam [W]	LED-3/6W / 180 mA - 4000 K	641.2	80
145-7673	symmetric, wide beam [W]	LED-3/9W / 250 mA - 2700 K	835.8	80
145-7676	symmetric, wide beam [W]	LED-3/9W / 250 mA - 3000 K	835.8	80
145-7679	symmetric, wide beam [W]	LED-3/9W / 250 mA - 4000 K	893.1	80
145-7674	symmetric, wide beam [W]	LED-3/12W / 350 mA - 2700 K	1122.1	80
145-7677	symmetric, wide beam [W]	LED-3/12W / 350 mA - 3000 K	1122.1	80
145-7680	symmetric, wide beam [W]	LED-3/12W / 350 mA - 4000 K	1213.7	80
145-7681	symmetric, medium beam [M]	LED-3/6W / 180 mA - 2700 K	600.4	80
145-7684	symmetric, medium beam [M]	LED-3/6W / 180 mA - 3000 K	600.4	80
145-7687	symmetric, medium beam [M]	LED-3/6W / 180 mA - 4000 K	646.6	80
145-7682	symmetric, medium beam [M]	LED-3/9W / 250 mA - 2700 K	842.9	80
145-7685	symmetric, medium beam [M]	LED-3/9W / 250 mA - 3000 K	842.9	80
145-7688	symmetric, medium beam [M]	LED-3/9W / 250 mA - 4000 K	900.6	80
145-7683	symmetric, medium beam [M]	LED-3/12W / 350 mA - 2700 K	1131.6	80
145-7686	symmetric, medium beam [M]	LED-3/12W / 350 mA - 3000 K	1131.6	80
145-7689	symmetric, medium beam [M]	LED-3/12W / 350 mA - 4000 K	1224	80
145-7690	symmetric, very narrow beam [VN]	LED-3/6W / 180 mA - 2700 K	605.2	80
145-7693	symmetric, very narrow beam [VN]	LED-3/6W / 180 mA - 3000 K	605.2	80
145-7696	symmetric, very narrow beam [VN]	LED-3/6W / 180 mA - 4000 K	651.7	80
145-7691	symmetric, very narrow beam [VN]	LED-3/9W / 250 mA - 2700 K	849.6	80
145-7694	symmetric, very narrow beam [VN]	LED-3/9W / 250 mA - 3000 K	849.6	80
145-7697	symmetric, very narrow beam [VN]	LED-3/9W / 250 mA - 4000 K	907.8	80
145-7692	symmetric, very narrow beam [VN]	LED-3/12W / 350 mA - 2700 K	1140.5	80
145-7695	symmetric, very narrow beam [VN]	LED-3/12W / 350 mA - 3000 K	1140.5	80
145-7698	symmetric, very narrow beam [VN]	LED-3/12W / 350 mA - 4000 K	1233.6	80
145-7699	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-3/6W / 180 mA - 2700 K	606.3	80
145-7702	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-3/6W / 180 mA - 3000 K	606.3	80
145-7705	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-3/6W / 180 mA - 4000 K	656.8	80
145-7700	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-3/9W / 250 mA - 2700 K	858.9	80
145-7703	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-3/9W / 250 mA - 3000 K	858.9	80
145-7706	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-3/9W / 250 mA - 4000 K	922	80
145-7701	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-3/12W / 350 mA - 2700 K	1149.4	80
145-7704	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-3/12W / 350 mA - 3000 K	1149.4	80
145-7707	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-3/12W / 350 mA - 4000 K	1237.8	80
145-7690	linear spread, very narrow beam [VN]	LED-3/6W / 180 mA - 2700 K	539.2	80
145-7693	linear spread, very narrow beam [VN]	LED-3/6W / 180 mA - 3000 K	539.2	80
145-7696	linear spread, very narrow beam [VN]	LED-3/6W / 180 mA - 4000 K	580.6	80
145-7691	linear spread, very narrow beam [VN]	LED-3/9W / 250 mA - 2700 K	756.9	80
145-7694	linear spread, very narrow beam [VN]	LED-3/9W / 250 mA - 3000 K	756.9	80
145-7697	linear spread, very narrow beam [VN]	LED-3/9W / 250 mA - 4000 K	808.7	80
145-7692	linear spread, very narrow beam [VN]	LED-3/12W / 350 mA - 2700 K	1016.1	80
145-7695	linear spread, very narrow beam [VN]	LED-3/12W / 350 mA - 3000 K	1016.1	80
145-7698	linear spread, very narrow beam [VN]	LED-3/12W / 350 mA - 4000 K	1099.1	80
145-7699	linear spread, very narrow beam, 'sharp cut-off'	LED-3/6W / 180 mA - 2700 K	528.4	80
145-7702	linear spread, very narrow beam, 'sharp cut-off'	LED-3/6W / 180 mA - 3000 K	528.4	80
145-7705	linear spread, very narrow beam, 'sharp cut-off'	LED-3/6W / 180 mA - 4000 K	572.4	80
145-7700	linear spread, very narrow beam, 'sharp cut-off'	LED-3/9W / 250 mA - 2700 K	748.5	80
145-7703	linear spread, very narrow beam, 'sharp cut-off'	LED-3/9W / 250 mA - 3000 K	748.5	80

Showing 1 to 50 of 63 entries.

Accessories

Control

Optical Accessories

Part-ID	Title	Specifications
		Text	PDF
0026	Low voltage DALI interface
