FLC210-CC LED
Family Spec SheetRGBW/RGBA Colour Changer. IP66, Class III. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. One cable gland. Second gland for through-wiring on request. Electronic control gear in separate gear box (constant current), prewired. Gearbox to be ordered separately. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Factory-installed LED circuit board, Colour Boost Technology. DMX interface.
Colors
RAL9004 Signal black
RAL9006 White aluminium
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
RAL8019 Grey brown
Powdercoat finish available in 35 different colours
Material
| Body | Marine-grade, die-cast aluminium alloy |
| Fasteners | PCS Polymer Coated Stainless Steel Hardware |
| Gasket | CCG® Silicone rubber gasket |
| Impact Protection | IK07 |
| Ingress Protection | IP66 |
| Finish | |
| Corrosion Protection | 5CE |
| Mounting | Pre-assembled connection cable possible (0,4m, 1m, 1,5m, 3m or 6m) |
Electrical
| Ballast / Driver | DMX |
| Cable | One cable gland, second gland for through-wiring on request |
| Power Factor | > 0.9 |
| Power Supply | 220-240V / 50-60 Hz |
| Surge Protection | SP10 (separate driver box - large) |
Additional Information
| Lifetime | Ta=25° L90B10 > 90000h |
| Energy efficiency class | G (Light source) |
- - - -
