IP69K. Class I. IK10+. Stainless steel construction. PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens; max load 5.5 tons (11,000 lbs). Luminaire can be driven over at low speed. Cable gland with spiral cable bending protection. Factory-sealed termination chamber complete with cable gland and 3 ft of flexible PVC-free, gel-impregnated anti-wicking cable. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. Gimbal mounted, 355° rotatable and 20° tiltable. 'No tool' removable gear/lens tray. Suitable for flush installation in concrete or earth. The concrete-pour installation blockout is supplied as standard with luminaire. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Colors

Stainless Steel

Material

Body	Luminaire body constructed of deep drawn stainless steel. Outer housing composite material.
Lens	5/8" thick clear tempered glass lens. Max. load 5 tonnes.
Fasteners	PCS polymer coated stainless steel
Gasket	Silicone rubber gasket
Impact Protection	IK10+
Ingress Protection	IP67
Finish	Natural stainless steel
Corrosion Protection	5CE
Mounting	Suitable for installation in concrete or earth. Suitable for walk-over and drive-over applications. Proper drainage and foundation support must be provided.

Electrical

Ballast / Driver	5/8" thick clear tempered glass lens. Max. load 5 tonnes.
Cable	3 feet of flexible 18/3 cable
Power Supply	Integral [ECG] electronic driver 120V-277V
Surge Protection	Factory sealed termination chamber

Additional Information

Diameter (inches)

6.3
