RGBW/RGBA Color Changer. ASC Lens accessory can be added. IP69K. Class I. IK10+. Stainless steel construction. PCS hardware. Optional with Anti-Slip ceramic Coating ASC to DIN 51130 (Trip Classification 10) available on request. Silicone CCG® Controlled Compression Gasket. Safety glass lens; max load 5.5 tons (11,000 lbs). Luminaire can be driven over at low speed. Cable gland with spiral cable bending protection. Factory-sealed termination chamber complete with cable gland and 3 ft of flexible PVC-free, gel-impregnated anti-wicking cable. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. Color Boost technology. DMX interface. Gimbal mounted, 360° rotatable and 30° tiltable. 'No tool' removable gear/lens tray. Suitable for flush installation in concrete or earth. The concrete-pour installation blockout is supplied as standard with luminaire. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black). + XXX-XXXX (Accessory 1)

ETC130-GB-CC LED COLOR CHANGER Schematics
Colors
Material

Body: Luminaire body constructed of deep drawn stainless steel, outer housing of composite material

Fasteners: PCS Polymer Coated Stainless Steel Hardware

Gasket: Silicone CCG® Controlled Compression Gasket

Impact Protection: IK10+

Ingress Protection: IP69K - HIGHEST PROTECTION RATING AVAILABLE

Finish:

Corrosion Protection:

Mounting: Suitable for installation in concrete or earth. Suitable for walk-over and DRIVE-OVER applications. Proper drainage and foundation support must be provided.

Electrical

Ballast / Driver: Integral driver

Cable: 3 ft of flexible PVC-free cable

Power Factor: > 0.9

Power Supply: Integral DMX 120V-277V Driver

Surge Protection:

Additional Information

Lifetime: Ta=25°/40° L90B10 > 90000h

:

:

Light Distribution

Delivered Lumen

To
Part-IDLight DistributionLight SourceLumenCRIOpen DataPDFIES, LDT, ULD
185-3389symmetric, wide beam [W]LED-12/19W - RGBW/4K1331.320/80
185-3390symmetric, medium beam [M]LED-12/19W - RGBW/4K1327.420/80
185-3391asymmetric, wallgrazer [A6]LED-12/19W - RGBW/4K1296.920/80
185-3392wallwashLED-12/19W - RGBW/4K1225.620/80
185-3414symmetric, wide beam [W]LED-12/19W - RGBA1123.320
185-3415symmetric, medium beam [M]LED-12/19W - RGBA112020
185-3416asymmetric, wallgrazer [A6]LED-12/19W - RGBA1094.220
185-3417wallwashLED-12/19W - RGBA1034.120
Showing 1 to 8 of 8 Entries

Accessories

Part-IDTitlePDFOpen Data
Please select an accessory category
ItemDownloadMail Link
Product Images
Light Distributions
Install Instructions
Manual
WE-EF Technical Information - DMX Wiring Diagram
WE-EF IP69K Ingrades Overview
WE-EF Technical Information - DMX LIGHTING USER MANUAL
