RFL540-SE LED

Back
Family Spec Sheet
RFL530-SE RFL530-SE 100 mm 100 mm 460 mm 460 mm
RFL540-SE RFL540-SE 120 mm 120 mm 570 mm 570 mm

IP66, Class I. Class II on request. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Non-reflecting safety glass lens, hinged with safety switch. Integral EC electronic converter in thermally separated compartment. DALI. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. The luminaire is factory-sealed and does not need to be opened during installation.
Variant with 2200 K or as 'Wild-Light' 2200 K combined with 3000 K with Eco Step Dim® Advanced or Motion available on request, must be specified at time of ordering. For further details and available variants see below under additional information – Wild-Light Presentation. Contact WE-EF direct or your local WE-EF sales representative for an individual solution designed to precisely meet your needs. Brackets to be ordered separately.

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK07
SchutzartIP66
AbdeckungPowdercoat finish in RAL7016, RAL9004, RAL9006, RAL9007 and RAL9016
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberIntegral EC electronic converter. DALI
Kabel
Leistungsfaktor> 0.9
Netz220-240V / 50-60 Hz
Überspannungsschutz6/6 kV (optional SP10)

Weitere Eigenschaften

LifetimeTa=25° L90B10 > 90000h
Energy efficiency classC-D (Light source)

Lichtverteilung

Lichtstrom (lm)

Leistung (W)

Farbtemperatur (K)

CRI

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
111-0188asymmetric, side throw beam [S60]LED-48/96W / 700 mA - 3000 K12507.780EC15.00
111-0190asymmetric, side throw beam [S60]LED-36/72W / 700 mA - 3000 K9380.880EC15.00
111-0218asymmetric, side throw [S70]LED-48/96W / 700 mA - 3000 K11936.280EC15.00
111-0228asymmetric, side throw [S70]LED-36/72W / 700 mA - 3000 K8952.280EC15.00
111-0283asymmetric, forward throw [A60]LED-36/72W / 700 mA - 3000 K8675.280EC15.00
111-0285asymmetric, forward throw [A60]LED-48/96W / 700 mA - 3000 K11566.980EC15.00
111-0343asymmetric, side throw beam [S60]LED-48/96W / 700 mA - 4000 K13370.380EC15.00
111-0349asymmetric, side throw [S70]LED-36/72W / 700 mA - 4000 K9569.680EC15.00
111-0351asymmetric, side throw [S70]LED-48/96W / 700 mA - 4000 K12759.480EC15.00
111-0357asymmetric, forward throw [A60]LED-36/72W / 700 mA - 4000 K9273.580EC15.00
111-0359asymmetric, forward throw [A60]LED-48/96W / 700 mA - 4000 K12364.680EC15.00
111-0420asymmetric, side throw beam [S60]LED-36/36W / 350 mA - 4000 K567380EC15.00
111-0421asymmetric, side throw beam [S60]LED-48/48W / 350 mA - 4000 K7563.980EC15.00
111-0422asymmetric, side throw beam [S65]LED-36/36W / 350 mA - 4000 K5679.280EC15.00
111-0423asymmetric, side throw beam [S65]LED-36/72W / 700 mA - 4000 K10044.180EC15.00
111-0424asymmetric, side throw beam [S65]LED-48/48W / 350 mA - 4000 K7572.380EC15.00
111-0425asymmetric, side throw beam [S65]LED-48/96W / 700 mA - 4000 K13392.280EC15.00
111-0426asymmetric, side throw [S70]LED-36/36W / 350 mA - 4000 K5510.180EC15.00
111-0427asymmetric, side throw [S70]LED-48/48W / 350 mA - 4000 K7346.880EC15.00
111-0428asymmetric, forward throw [A60]LED-36/36W / 350 mA - 4000 K5353.180EC15.00
111-0429asymmetric, forward throw [A60]LED-48/48W / 350 mA - 4000 K7137.580EC15.00
111-0430rectangular, side throw [R65]LED-36/36W / 350 mA - 4000 K5341.880EC15.00
111-0431rectangular, side throw [R65]LED-36/72W / 700 mA - 4000 K9252.880EC15.00
111-0432rectangular, side throw [R65]LED-48/48W / 350 mA - 4000 K7122.480EC15.00
111-0433rectangular, side throw [R65]LED-48/96W / 700 mA - 4000 K12337.180EC15.00
Showing 1 to 25 of 200 Entries
