RFL540-SE LED
Fiche technique de la famille Instructions d'installation Autres téléchargements

Wall and pole mounted LED luminaire. IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Non-reflecting safety glass lens hinged, tool-less entry. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation. Recommended mounting height 10-30 ft, depending on wattage and light distribution selected. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1) For DarkSky compliant configurations of this product, please find the spec sheet and DarkSky certificate in the library.

RFL540-SE LED Schematics
Couleurs
RAL9004 Black
RAL9007 Grey Metallic
RAL9016 White
RAL8019 Dark Bronze
Description du matériel
CorpsMarine-grade die-cast aluminium alloy
VisseriePCS Polymer Coated Stainless Steel hardware
JointSilicone rubber gasket
IKIK07
IPIP66
FinitionPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019
Protection contre la corrosion5CE
MontageMaximum spacing for streetlighting applications depends on wattage and light distribution: 5.5 to 9 times the mounting height.
Description électrique
DriverIntegral EC electronic converter
Facteur de puissance> 0.9
Alimentation électriqueIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Protection contre les surtensionsIn-line bracket 10kV Surge Protector
Informations complémentaires
LifetimeTa=25°/40° L90B10 > 90000h
BUG RatingPlease see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Données en sortie de luminaire

To

Puissance

To
Code produitDistribution photométriqueSource lumineuseDonnées en sortie de luminaireIRCCaractéristiquesPhotométrie
TextePDF
111-0188[S60] Type III ShortLED-48/96W / 700 mA - 3000 K12507.780
111-0190[S60] Type III ShortLED-36/72W / 700 mA - 3000 K9380.880
111-0218[S70] Type II ShortLED-48/96W / 700 mA - 3000 K11936.280
111-0228[S70] Type II ShortLED-36/72W / 700 mA - 3000 K8952.280
111-0283[A60] Type IV Very ShortLED-36/72W / 700 mA - 3000 K8675.280
111-0285[A60] Type IV Very ShortLED-48/96W / 700 mA - 3000 K11566.980
111-0343[S60] Type III ShortLED-48/96W / 700 mA - 4000 K13370.380
111-0349[S70] Type II ShortLED-36/72W / 700 mA - 4000 K9569.680
111-0351[S70] Type II ShortLED-48/96W / 700 mA - 4000 K12759.480
111-0357[A60] Type IV Very ShortLED-36/72W / 700 mA - 4000 K9273.580
111-0359[A60] Type IV Very ShortLED-48/96W / 700 mA - 4000 K12364.680
111-0420[S60] Type III ShortLED-36/36W / 350 mA - 4000 K567380
111-0421[S60] Type III ShortLED-48/48W / 350 mA - 4000 K7563.980
111-0422[S65] Type III MediumLED-36/36W / 350 mA - 4000 K5679.280
111-0423[S65] Type III MediumLED-36/72W / 700 mA - 4000 K10044.180
111-0424[S65] Type III MediumLED-48/48W / 350 mA - 4000 K7572.380
111-0425[S65] Type III MediumLED-48/96W / 700 mA - 4000 K13392.280
111-0426[S70] Type II ShortLED-36/36W / 350 mA - 4000 K5510.180
111-0427[S70] Type II ShortLED-48/48W / 350 mA - 4000 K7346.880
111-0428[A60] Type IV Very ShortLED-36/36W / 350 mA - 4000 K5353.180
111-0429[A60] Type IV Very ShortLED-48/48W / 350 mA - 4000 K7137.580
111-0430[R65] Type IV MediumLED-36/36W / 350 mA - 4000 K5341.880
111-0431[R65] Type IV MediumLED-36/72W / 700 mA - 4000 K9252.880
111-0432[R65] Type IV MediumLED-48/48W / 350 mA - 4000 K7122.480
111-0433[R65] Type IV MediumLED-48/96W / 700 mA - 4000 K12337.180
111-0475[S60] Type III ShortLED-36/36W / 350 mA - 3000 K5172.480
111-0477[S60] Type III ShortLED-48/48W / 350 mA - 3000 K6896.580
111-0479[S65] Type III MediumLED-36/36W / 350 mA - 3000 K5178.180
111-0481[S65] Type III MediumLED-36/72W / 700 mA - 3000 K9396.180
111-0483[S65] Type III MediumLED-48/48W / 350 mA - 3000 K6904.280
111-0485[S65] Type III MediumLED-48/96W / 700 mA - 3000 K12528.280
111-0487[S70] Type II ShortLED-36/36W / 350 mA - 3000 K5023.980
111-0489[S70] Type II ShortLED-48/48W / 350 mA - 3000 K6698.680
111-0491[A60] Type IV Very ShortLED-36/36W / 350 mA - 3000 K4880.880
111-0493[A60] Type IV Very ShortLED-48/48W / 350 mA - 3000 K6507.780
111-0495[R65] Type IV MediumLED-36/36W / 350 mA - 3000 K4870.580
111-0497[R65] Type IV MediumLED-36/72W / 700 mA - 3000 K8655.980
111-0944[R65] Type IV MediumLED-48/48W / 350 mA - 3000 K649480
111-0501[R65] Type IV MediumLED-48/96W / 700 mA - 3000 K11541.280
111-0341[S60] Type III ShortLED-36/72W / 700 mA - 4000 K10027.780
111-0888pedestrian crossing, left-hand traffic [P45L]LED-36/72W / 700 mA - 3000 K8904.780
111-0890pedestrian crossing, right-hand traffic [P45R]LED-36/72W / 700 mA - 3000 K8765.780
111-0889pedestrian crossing, left-hand traffic [P45L]LED-36/72W / 700 mA - 4000 K9518.880
111-0891pedestrian crossing, right-hand traffic [P45R]LED-36/72W / 700 mA - 4000 K9370.380
111-0892pedestrian crossing, left-hand traffic [P45L]LED-48/96W / 700 mA - 3000 K11872.980
111-0894pedestrian crossing, right-hand traffic [P45R]LED-48/96W / 700 mA - 3000 K11687.680
111-0893pedestrian crossing, left-hand traffic [P45L]LED-48/96W / 700 mA - 4000 K12691.880
111-0895pedestrian crossing, right-hand traffic [P45R]LED-48/96W / 700 mA - 4000 K12493.780
111-0920[A60] Type IV Very ShortLED-36/108W / 1050 mA - 3000 K13770.780
111-0921[A60] Type IV Very ShortLED-36/108W / 1050 mA - 4000 K14411.280
Affichage de 1 à 50 sur 102 résultats

Accessories

Code produitTitreCaractéristiques
TextePDF
111-0084RE0-540 Wall bracket
111-0042RE1-540 Pole bracket, single
111-0043RE2-540 Pole bracket, double
ItemDownload
Images du produit
Photométrie
Instructions d'installation
WE-EF General Catalogue 2021 - Pole mounted luminaires
WE-EF EPD - RFL500-SE SERIES
