FLC121 LED - Wall bracket

#4

Back
Wallbracket
Spigot Mounted
Surface Mounted
Family Spec Sheet
Standard Projector Standard Projector 112 mm 112 mm
Standard Projector Standard Projector 115 mm 115 mm
Standard Projector Standard Projector 193 mm 193 mm
Micro Projector Micro Projector 58 mm 58 mm
Micro Projector Micro Projector 85 mm 85 mm
Micro Projector Micro Projector 115 mm 115 mm

IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire.
Knuckle permits 350° horizontal and 90° vertical aiming of optics. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black). + XXX-XXXX (Accessory 1)

Eigenschaften

Material

GehäuseMarine-grade, all-aluminium construction
SchraubenPCS Polymer Coated Stainless Steel hardware
FarbenPending
DichtungSilicone rubber gasket
SchlagfestigkeitIK07
SchutzartIP55
AbdeckungPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019
Korrosionsschutz5CE
BefestigungMOUNTING: Suitable for installation over a 4” recessed junction box.

Elektrik

LED TreiberIntegral EC electronic converter in thermally-separated compartment
Kabel
Leistungsfaktor
NetzIntegral [ECG] electronic 0-10 V dimmable driver in 120-277 universal voltage
ÜberspannungsschutzIntegral 10kV Surge Protector

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h
Other Color Temperatures2700K, 3500K, 5000K and True Amber available on request.

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
145-0037symmetric, medium beam [M]LED-6/12W / 700 mA - 3000 K1511.880electronic gear6.40
145-0038symmetric, medium beam [M]LED-6/12W / 700 mA - 4000 K1616.180electronic gear6.40
145-0040symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-6/12W / 700 mA - 3000 K1610.780electronic gear6.40
145-0040linear spread, very narrow beam, 'sharp cut-off'LED-6/12W / 700 mA - 3000 K1526.280electronic gear6.40
145-0041symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-6/12W / 700 mA - 4000 K1721.880electronic gear6.40
145-0041linear spread, very narrow beam, 'sharp cut-off'LED-6/12W / 700 mA - 4000 K1631.580electronic gear6.40
145-0070symmetric, wide beam [W]LED-6/12W / 700 mA - 3000 K1347.180electronic gear6.40
145-0071symmetric, wide beam [W]LED-6/12W / 700 mA - 4000 K144080electronic gear6.40
145-0073symmetric, very narrow beam [VN]LED-6/12W / 700 mA - 3000 K1496.580electronic gear6.40
145-0073linear spread, very narrow beam [VN]LED-6/12W / 700 mA - 3000 K1386.380electronic gear6.40
145-0074symmetric, very narrow beam [VN]LED-6/12W / 700 mA - 4000 K1599.780electronic gear6.40
145-0074linear spread, very narrow beam [VN]LED-6/12W / 700 mA - 4000 K1481.980electronic gear6.40
145-0038wallwashLED-6/12W / 700 mA - 4000 K1296.680electronic gear6.40
145-0037wallwashLED-6/12W / 700 mA - 3000 K121380electronic gear6.40
145-0293symmetric, wide beam [W]LED-6/12W / 700 mA - 2700 K1254.280electronic gear6.40
145-0294symmetric, medium beam [M]LED-6/12W / 700 mA - 2700 K1407.580electronic gear6.40
145-0295symmetric, very narrow beam [VN]LED-6/12W / 700 mA - 2700 K1393.380electronic gear6.40
145-0296symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-6/12W / 700 mA - 2700 K1499.680electronic gear6.40
145-0294wallwashLED-6/12W / 700 mA - 2700 K1129.380electronic gear6.40
145-0295linear spread, very narrow beam [VN]LED-6/12W / 700 mA - 2700 K1290.780electronic gear6.40
145-0296linear spread, very narrow beam, 'sharp cut-off'LED-6/12W / 700 mA - 2700 K142180electronic gear6.40
Showing 1 to 21 of 21 Entries
