FLC100 series

FLC121 LED - Ceon

Static White

Choose a variant:

Spigot
Surface
Wallbracket

Choose a family:

FLC121 LED - Ceon
Diameter ⌀: 4.41 in
FLC131 LED - Ceon
Diameter ⌀: 6.10 in
FLC141 LED - Ceon
Diameter ⌀: 7.60 in
Home
Products
Floodlights
FLC121 LED - Ceon
Family Spec Sheet Installation Instructions More Downloads

IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation. Knuckle permits 350° horizontal and 90° vertical aiming of optics. Suitable for pole or surface mount. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

FLC121 LED - Ceon Schematics
Colors
RAL9004 Black
RAL9007 Grey Metallic
RAL9016 White
RAL8019 Dark Bronze
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS Polymer Coated Stainless Steel Hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK07
Ingress ProtectionIP66
Corrosion Protection5CE
Electrical
Ballast / DriverRemote EC electronic converter (sold seperatly)
Power SupplyIntegral [ECG] electronic 0-10 V dimmable driver in 120-277 universal voltage
Additional Information
LifetimeLED >60,000 h Ta 25°(L70/B10) Control gear >50,000 h Ta 25°
Other Color Temperatures2700K, 3500K, 5000K and True Amber available on request.

Rated Lumen

Part-IDLight DistributionLight SourceRated LumenCRISpecificationsPhotometrics
TextPDF
145-6506symmetric, wide beam [W]LED-6/12W / 700 mA - 3000 K1347.180 ULD
145-6507symmetric, wide beam [W]LED-6/12W / 700 mA - 4000 K144080 ULD
145-6504symmetric, medium beam [M]LED-6/12W / 700 mA - 3000 K1511.880 ULD
145-6505symmetric, medium beam [M]LED-6/12W / 700 mA - 4000 K1616.180 ULD
145-6502symmetric, very narrow beam [VN]LED-6/12W / 700 mA - 3000 K1496.580 ULD
145-6503symmetric, very narrow beam [VN]LED-6/12W / 700 mA - 4000 K1599.780 ULD
145-6500symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-6/12W / 700 mA - 3000 K1610.780 ULD
145-6501symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-6/12W / 700 mA - 4000 K1721.880 ULD
145-6504wallwash [A20]LED-6/12W / 700 mA - 3000 K121380
145-6505wallwash [A20]LED-6/12W / 700 mA - 4000 K1296.680
145-6502linear spread, very narrow beam [VN]LED-6/12W / 700 mA - 3000 K1386.380
145-6503linear spread, very narrow beam [VN]LED-6/12W / 700 mA - 4000 K1481.980
145-6500linear spread, very narrow beam, 'sharp cut-off'LED-6/12W / 700 mA - 3000 K1526.280
145-6501linear spread, very narrow beam, 'sharp cut-off'LED-6/12W / 700 mA - 4000 K1631.580
Showing 1 to 14 of 14 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
145-0030Snoot ET
