FLC100 series

FLC121 LED Wall bracket

Static White

Choose a variant:

Surface
Wallbracket

Choose a family:

FLC121 LED Wall bracket
Diameter ⌀: 112 mm
FLC131 LED Wall bracket
Diameter ⌀: 155 mm
FLC141 LED Wall bracket
Diameter ⌀: 193 mm
Home
Products
Projectors
FLC121 LED Wall bracket
Family Spec Sheet Installation Instructions More Downloads

IP66, Class I. IK07. Marine-grade, all-aluminium construction. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Two cable entries. Knuckle permits 350° horizontal and 180° vertical aiming of optics.

FLC121 LED Wall bracket Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, all-aluminium construction
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK07
Ingress ProtectionIP66
FinishPowdercoat finish in black RAL 9004, grey aluminium RAL 9007 or white RAL 9016
Corrosion Protection5CE
MountingTwo cable entries
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-separated compartment
Power Supply220-240V / 50-60 Hz
Additional Information
LifetimeTa=25° L90B10 > 90000h

Rated Lumen

Part-IDLight DistributionLight SourceRated LumenCRISpecificationsPhotometrics
TextPDF
145-0037symmetric, medium beam [M]LED-6/12W / 700 mA - 3000 K1511.880 ULD
145-0038symmetric, medium beam [M]LED-6/12W / 700 mA - 4000 K1616.180 ULD
145-0040symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 3000 K1610.780 ULD
145-0040linear spread, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 3000 K1526.280 ULD
145-0041symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 4000 K1721.880 ULD
145-0041linear spread, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 4000 K1631.580 ULD
145-0070symmetric, wide beam [B]LED-6/12W / 700 mA - 3000 K1347.180 ULD
145-0071symmetric, wide beam [B]LED-6/12W / 700 mA - 4000 K144080 ULD
145-0073symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 3000 K1496.580 ULD
145-0073linear spread, very narrow beam [EE]LED-6/12W / 700 mA - 3000 K1386.380 ULD
145-0074symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 4000 K1599.780 ULD
145-0074linear spread, very narrow beam [EE]LED-6/12W / 700 mA - 4000 K1481.980 ULD
145-0038wallwashLED-6/12W / 700 mA - 4000 K1296.680 ULD
145-0037wallwashLED-6/12W / 700 mA - 3000 K121380 ULD
145-0293symmetric, wide beam [B]LED-6/12W / 700 mA - 2700 K1254.280 ULD
145-0294symmetric, medium beam [M]LED-6/12W / 700 mA - 2700 K1407.580 ULD
145-0295symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 2700 K1393.380 ULD
145-0296symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 2700 K1499.680 ULD
145-0294wallwashLED-6/12W / 700 mA - 2700 K1129.380 ULD
145-0295linear spread, very narrow beam [EE]LED-6/12W / 700 mA - 2700 K1290.780 ULD
145-0296linear spread, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 2700 K142180 ULD
Showing 1 to 21 of 21 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
145-0030Snoot ET
