FLC141 LED - Wall bracket

#4

Back
Wallbracket
Spigot Mounted
Surface Mounted
Family Spec Sheet
Standard Projector Standard Projector 112 mm 112 mm
Standard Projector Standard Projector 115 mm 115 mm
Standard Projector Standard Projector 193 mm 193 mm
Micro Projector Micro Projector 58 mm 58 mm
Micro Projector Micro Projector 85 mm 85 mm
Micro Projector Micro Projector 115 mm 115 mm

IP55. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire.
Knuckle permits 350° horizontal and 90° vertical aiming of optics. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Eigenschaften

Material

GehäuseMarine-grade die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel hardware
FarbenPending
DichtungSilicone rubber gasket
SchlagfestigkeitIK07
SchutzartIP55
AbdeckungPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019
Korrosionsschutz5CE
BefestigungSuitable for installation over 4" recessed junction box

Elektrik

LED TreiberIntegral EC electronic converter in thermally-separated compartment
Kabel
Leistungsfaktor
NetzIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
ÜberspannungsschutzIntegral 10kV Surge Protector

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
146-7054symmetric, medium beam [M]LED-24/48W / 700 mA - 3000 K6047.280electronic gear12.80
146-7055symmetric, medium beam [M]LED-24/48W / 700 mA - 4000 K6464.280electronic gear12.80
146-7056symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-24/48W / 700 mA - 3000 K6442.780electronic gear12.80
146-7057symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-24/48W / 700 mA - 4000 K688780electronic gear12.80
146-7066symmetric, wide beam [W]LED-24/48W / 700 mA - 3000 K5388.580electronic gear12.80
146-7067symmetric, wide beam [W]LED-24/48W / 700 mA - 4000 K5760.180electronic gear12.80
146-7068symmetric, very narrow beam [VN]LED-24/48W / 700 mA - 3000 K5986.180electronic gear12.80
146-7069symmetric, very narrow beam [VN]LED-24/48W / 700 mA - 4000 K6398.980electronic gear12.80
146-7068linear spread, very narrow beam [VN]LED-24/48W / 700 mA - 3000 K5545.280electronic gear12.80
146-7069linear spread, very narrow beam [VN]LED-24/48W / 700 mA - 4000 K5927.680electronic gear12.80
146-7056linear spread, very narrow beam, 'sharp cut-off'LED-24/48W / 700 mA - 3000 K6104.980electronic gear12.80
146-7057linear spread, very narrow beam, 'sharp cut-off'LED-24/48W / 700 mA - 4000 K652680electronic gear12.80
146-7054wallwashLED-24/48W / 700 mA - 3000 K4851.980electronic gear12.80
146-7055wallwashLED-24/48W / 700 mA - 4000 K5186.680electronic gear12.80
146-0976symmetric, wide beam [W]LED-24/48W / 700 mA - 2700 K5016.980electronic gear12.80
146-0977symmetric, medium beam [M]LED-24/48W / 700 mA - 2700 K5630.180electronic gear12.80
146-0978symmetric, very narrow beam [VN]LED-24/48W / 700 mA - 2700 K5573.380electronic gear12.80
146-0979symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-24/48W / 700 mA - 2700 K5998.480electronic gear12.80
146-0977wallwashLED-24/48W / 700 mA - 2700 K4517.380electronic gear12.80
146-0978linear spread, very narrow beam [VN]LED-24/48W / 700 mA - 2700 K5162.880electronic gear12.80
146-0979linear spread, very narrow beam, 'sharp cut-off'LED-24/48W / 700 mA - 2700 K5683.980electronic gear12.80
Showing 1 to 21 of 21 Entries
