BSP534 LED

Back
Family Spec Sheet
BSP534 BSP534 375 mm 375 mm 560 mm 560 mm
BSP544 BSP544 430 mm 430 mm 700 mm 700 mm

IP55, Class I. Class II on request. IK10. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone rubber gasket. Polycarbonate main lens. Integral EC electronic converter in thermally separated compartment. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. The luminaire is factory-sealed and does not need to be opened during installation.
Optional 2200 K version available. To be specified at time of ordering. Brackets to be ordered separately.

Eigenschaften

Material

GehäuseMarine-grade die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone rubber gasket
SchlagfestigkeitIK10
SchutzartIP55
AbdeckungPowdercoat finish in RAL7016, RAL9004, RAL9006, RAL9007 and RAL9016
Korrosionsschutz5CE
BefestigungRecommended mounting height 3.0- 4.5 m, depending on wattage and light distribution.

Elektrik

LED TreiberIntegral EC electronic converter. DALI
Kabel
Leistungsfaktor> 0.9
Netz220-240V / 50-60 Hz
Überspannungsschutz6/6 kV (optional SP10)

Weitere Eigenschaften

LifetimeTa=25° L90B10 > 90000h
Energy efficiency classC-D (Light source)

Lichtverteilung

Lichtstrom (lm)

Leistung (W)

Farbtemperatur (K)

CRI

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
127-1269asymmetric, side throw beam [S65]LED-12/24W / 700 mA - 4000 K3164.680EC5.90
127-1270asymmetric, side throw beam [S65]LED-24/48W / 700 mA - 3000 K5920.980EC5.90
127-1271asymmetric, side throw beam [S65]LED-24/48W / 700 mA - 4000 K6329.380EC5.90
127-1272rectangular, side throw [R65]LED-12/24W / 700 mA - 3000 K2699.480EC5.90
127-1273rectangular, side throw [R65]LED-12/24W / 700 mA - 4000 K2885.680EC5.90
127-1274rectangular, side throw [R65]LED-24/48W / 700 mA - 3000 K5398.980EC5.90
127-1275rectangular, side throw [R65]LED-24/48W / 700 mA - 4000 K5771.280EC5.90
127-1268asymmetric, side throw beam [S65]LED-12/24W / 700 mA - 3000 K2960.580EC5.90
127-1429asymmetric, side throw beam [S65]LED-12/24W / 700 mA - 2700 K2756.380EC5.90
127-1430asymmetric, side throw beam [S65]LED-24/48W / 700 mA - 2700 K5512.680EC5.90
127-1431rectangular, side throw [R65]LED-12/24W / 700 mA - 2700 K2513.380EC5.90
127-1432rectangular, side throw [R65]LED-24/48W / 700 mA - 2700 K5026.580EC5.90
127-1429-70asymmetric, side throw beam [S65]LED-12/24W / 700 mA - 2700 K2960.570EC5.90
127-1431-70rectangular, side throw [R65]LED-12/24W / 700 mA - 2700 K2699.470EC5.90
127-1268-70asymmetric, side throw beam [S65]LED-12/24W / 700 mA - 3000 K3368.870EC5.90
127-1272-70rectangular, side throw [R65]LED-12/24W / 700 mA - 3000 K3071.870EC5.90
127-1269-70asymmetric, side throw beam [S65]LED-12/24W / 700 mA - 4000 K357370EC5.90
127-1273-70rectangular, side throw [R65]LED-12/24W / 700 mA - 4000 K3257.970EC5.90
127-1430-70asymmetric, side throw beam [S65]LED-24/48W / 700 mA - 2700 K5920.970EC5.90
127-1432-70rectangular, side throw [R65]LED-24/48W / 700 mA - 2700 K5398.970EC5.90
127-1270-70asymmetric, side throw beam [S65]LED-24/48W / 700 mA - 3000 K6737.670EC5.90
127-1274-70rectangular, side throw [R65]LED-24/48W / 700 mA - 3000 K6143.570EC5.90
127-1271-70asymmetric, side throw beam [S65]LED-24/48W / 700 mA - 4000 K714670EC5.90
127-1275-70rectangular, side throw [R65]LED-24/48W / 700 mA - 4000 K6515.970EC5.90
Showing 1 to 24 of 24 Entries
