FLC301 RAIL66

IP66. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. Mains voltage versions only, ON-OFF. Class I. 1-10 V analogue dimming or DALI interface available on request (converter in thermally-separated compartment); refer to accessory listings. Including 0.4 m of flexible cable enclosed in a stainless conduit, in-line connector and mounting clamp for installation to RAIL66 mounting system. Optical accessories are factory-installed. To be specified at time of ordering.

Colors

Material

Body: Marine-grade, die-cast aluminium alloy

Fasteners: PCS hardware

Gasket: Silicone CCG® Controlled Compression Gasket

Impact Protection: IK07

Ingress Protection: IP66

Finish:

Corrosion Protection: 5CE

Mounting: Including 1.3 ft of flexible cable enclosed in a stainless conduit, in-line connector and mounting clamp for installation to RAIL66 mounting system

Electrical

Ballast / Driver: Integral EC electronic converter

Cable: Including 0.4 m of flexible cable

Power Factor:

Power Supply:

Surge Protection:

Additional Information

Lifetime: Ta=25° L90B10 > 90000h

Energy efficiency class: D-E (Light source)

:

Light Distribution

Delivered Lumen

To

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
145-7216	symmetric, wide beam [B]	LED-1/4W / 350 mA – 2700 K	379.1	80
145-7217	symmetric, wide beam [B]	LED-1/4W / 350 mA – 3000 K	379.1	80
145-7218	symmetric, wide beam [B]	LED-1/4W / 350 mA – 4000 K	410.1	80
145-7219	symmetric, medium beam [M]	LED-1/4W / 350 mA – 2700 K	398.4	80
145-7220	symmetric, medium beam [M]	LED-1/4W / 350 mA – 3000 K	398.4	80
145-7221	symmetric, medium beam [M]	LED-1/4W / 350 mA – 4000 K	431	80
145-7249	symmetric, narrow beam [E]	LED-1/4W / 350 mA – 2700 K	415.2	80
145-7250	symmetric, narrow beam [E]	LED-1/4W / 350 mA – 3000 K	415.2	80
145-7251	symmetric, narrow beam [E]	LED-1/4W / 350 mA – 4000 K	449.1	80
145-7222	symmetric, very narrow beam [EE]	LED-1/4W / 350 mA – 2700 K	415.5	80
145-7223	symmetric, very narrow beam [EE]	LED-1/4W / 350 mA – 3000 K	415.5	80
145-7224	symmetric, very narrow beam [EE]	LED-1/4W / 350 mA – 4000 K	449.5	80
145-7225	symmetric, very narrow beam, sharp cut-off [EES]	LED-1/4W / 350 mA – 2700 K	382.2	80
145-7226	symmetric, very narrow beam, sharp cut-off [EES]	LED-1/4W / 350 mA – 3000 K	382.2	80
145-7227	symmetric, very narrow beam, sharp cut-off [EES]	LED-1/4W / 350 mA – 4000 K	411.6	80
145-7222	linear spread, very narrow beam [EE]	LED-1/4W / 350 mA – 2700 K	384.7	80
145-7223	linear spread, very narrow beam [EE]	LED-1/4W / 350 mA – 3000 K	406.1	80
145-7224	linear spread, very narrow beam [EE]	LED-1/4W / 350 mA – 4000 K	439.2	80
145-7225	linear spread, very narrow beam, sharp cut-off [EES]	LED-1/4W / 350 mA – 2700 K	343.5	80
145-7226	linear spread, very narrow beam, sharp cut-off [EES]	LED-1/4W / 350 mA – 3000 K	343.5	80
145-7227	linear spread, very narrow beam, sharp cut-off [EES]	LED-1/4W / 350 mA – 4000 K	369.9	80
145-7219	wallwash	LED-1/4W / 350 mA – 2700 K	331.7	80
145-7220	wallwash	LED-1/4W / 350 mA – 3000 K	331.7	80
145-7221	wallwash	LED-1/4W / 350 mA – 4000 K	358.8	80

Showing 1 to 24 of 24 Entries
