FLC100 series

FLC141 LED #1

Static White

Choose a variant:

Surface-Mounted

Spigot-Mounted

Wallbracket

Choose a family:

⌀112 mm | FLC121 LED #1 ⌀155 mm | FLC131 LED #1 ⌀193 mm | FLC141 LED #1

Family Spec Sheet Installation Instructions More Downloads

IP66, Class I. IK07. Marine-grade die-cast aluminium alloy. 5CE superior corrosion protection + primer including PCS hardware. Silicone CCG® Controlled Compression Gasket Safety glass lens. PMMA-LED lens array. Remote 240v gear to be ordered separately. 2700 K option available on request.

Colours

RAL9004 Signal black

RAL9006 White aluminium

RAL9007 Grey aluminium

Material

Body	Marine-grade die-cast aluminium alloy
Fasteners	PCS Polymer Coated Stainless Steel Hardware (unpainted)
Gasket	Silicone CCG® Controlled Compression Gasket
Impact Protection	IK07
Ingress Protection	IP66
Finish	Powdercoat finish in black RAL9004, grey aluminium RAL9007, white aluminium RAL9006 or white RAL9016
Corrosion Protection	5CE+Primer

Electrical

Cable

1.5m cable (to be wired to separately supplied constant current control gear box)

Additional Information

Warranty

The product is supplied with 10-year warranty. Please refer to the LED Warranty Statement located on www.we-ef.com for further details.

Light Distribution

Delivered Lumen

Wattage

Colour Temperature

CRI

Part-ID	Light Distribution	Light Source	Delivered Lumen	CRI	Specifications
					Text	PDF
146-0573	symmetric, wide beam [B]	LED-24/48W / 700 mA - 3000 K	5388.5	80
146-0574	symmetric, wide beam [B]	LED-24/48W / 700 mA - 4000 K	5760.1	80
146-0576	symmetric, medium beam [M]	LED-24/48W / 700 mA - 3000 K	6047.2	80
146-0577	symmetric, medium beam [M]	LED-24/48W / 700 mA - 4000 K	6464.2	80
146-0579	symmetric, very narrow beam [EE]	LED-24/48W / 700 mA - 3000 K	5986.1	80
146-0580	symmetric, very narrow beam [EE]	LED-24/48W / 700 mA - 4000 K	6398.9	80
146-0582	symmetric, very narrow beam, sharp cut-off [EES]	LED-24/48W / 700 mA - 3000 K	6442.7	80
146-0583	symmetric, very narrow beam, sharp cut-off [EES]	LED-24/48W / 700 mA - 4000 K	6887	80
146-8576	symmetric, medium beam [M]	LED-24/48W - RGBW	2963.9	20/80
146-8574	symmetric, wide beam [B]	LED-24/48W - RGBW	2666.8	20/80
146-8575	symmetric, very narrow beam [EE]	LED-24/48W - RGBW	2921.6	20/80
146-0579	linear spread, very narrow beam [EE]	LED-24/48W / 700 mA - 3000 K	5545.2	80
146-0580	linear spread, very narrow beam [EE]	LED-24/48W / 700 mA - 4000 K	5927.6	80
146-0582	linear spread, very narrow beam, sharp cut-off [EES]	LED-24/48W / 700 mA - 3000 K	6104.9	80
146-0583	linear spread, very narrow beam, sharp cut-off [EES]	LED-24/48W / 700 mA - 4000 K	6526	80

Showing 1 to 15 of 15 entries.

Accessories

	Part-ID	Title	Specifications
	146-0229	Glare shield ES
