FLC100 Série

FLC121 LED #1

Static White

Choisissez une variante :

Surface-Mounted

Spigot-Mounted

Wallbracket

Choisissez une famille :

⌀112 mm | FLC121 LED #1 ⌀155 mm | FLC131 LED #1 ⌀193 mm | FLC141 LED #1

Fiche technique de la famille Instructions d'installation Autres téléchargements

IP66, Class I. IK07. Marine-grade die-cast aluminium alloy. 5CE superior corrosion protection + primer including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. PMMA-LED lens array. Remote 240v gear to be ordered separately. 2700 K option available on request.

Couleurs

RAL9004 Signal black

RAL9006 White aluminium

RAL9007 Grey aluminium

Description du matériel

Corps	Marine-grade die-cast aluminium alloy
Visserie	PCS Polymer Coated Stainless Steel Hardware (unpainted)
Joint	Silicone CCG® Controlled Compression Gasket
IK	IK07
IP	IP66
Finition	Powdercoat finish in black RAL9004, grey aluminium RAL9007, white aluminium RAL9006 or white RAL9016
Protection contre la corrosion	5CE+Primer

Description électrique

Câble

1.5m cable (to be wired to separately supplied constant current control gear box)

Informations complémentaires

Warranty

The product is supplied with 10-year warranty. Please refer to the LED Warranty Statement located on www.we-ef.com for further details.

Distribution photométrique

Données en sortie de luminaire

Température de couleur

Code produit	Distribution photométrique	Source lumineuse	Données en sortie de luminaire	IRC	Caractéristiques
					Texte	PDF
145-0117	symmetric, wide beam [B]	LED-6/12W / 700 mA - 3000 K	1347.1	80
145-0118	symmetric, wide beam [B]	LED-6/12W / 700 mA - 4000 K	1440	80
145-0120	symmetric, medium beam [M]	LED-6/12W / 700 mA - 3000 K	1511.8	80
145-0121	symmetric, medium beam [M]	LED-6/12W / 700 mA - 4000 K	1616.1	80
145-0123	symmetric, very narrow beam [EE]	LED-6/12W / 700 mA - 3000 K	1496.5	80
145-0124	symmetric, very narrow beam [EE]	LED-6/12W / 700 mA - 4000 K	1599.7	80
145-0126	symmetric, very narrow beam, sharp cut-off [EES]	LED-6/12W / 700 mA - 3000 K	1610.7	80
145-0127	symmetric, very narrow beam, sharp cut-off [EES]	LED-6/12W / 700 mA - 4000 K	1721.8	80
145-0123	linear spread, very narrow beam [EE]	LED-6/12W / 700 mA - 3000 K	1386.3	80
145-0124	linear spread, very narrow beam [EE]	LED-6/12W / 700 mA - 4000 K	1481.9	80
145-0126	linear spread, very narrow beam, sharp cut-off [EES]	LED-6/12W / 700 mA - 3000 K	1526.2	80
145-0127	linear spread, very narrow beam, sharp cut-off [EES]	LED-6/12W / 700 mA - 4000 K	1631.5	80

Affichage de 1 à 12 sur 12 résultats

Accessories

Mounting Accessories

Electrical Accessories

Optical Accessories

Code produit	Titre	Caractéristiques
		Texte	PDF
310-9102	Ground spike EF1
