ETC330-FS TW LED
Tunable white inground. IP67, Class I. IK10+. Stainless steel construction including PCS hardware. Safety glass lens; max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Factory-sealed termination chamber complete with cable gland and 0.5 m of flexible PVC free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC_R_ One LED Concept. LED circuit board with Tunable White Technology. DALI Interface . For other control interface options to suit specific project requirements, contact WE-EF. Luminaire installation blockout and sealable junction box included in supply. IMPORTANT! Inground blockouts must be installed with effective drainage, watch here.
Farben
Materialinformationen
| Gehäuse | Stainless steel construction |
| Schrauben | PCS hardware |
| Dichtung | Silicone rubber gasket |
| Schlagfestigkeit | IK10+ |
| Schutzart | IP67 |
| Installation | Luminaire installation blockout and sealable junction box included in supply |
Elektrische Informationen
| Netzgerät / Vorschaltgerät | Integral EC electronic converter with DALI Interface |
| Kabel | Complete with cable gland and 0.5 m of flexible PVC-free cable |
Weitere Informationen
| Warranty | The product is supplied with 10-year warranty. Please refer to the LED Warranty Statement located on www.we-ef.com for further details. Warranty void if installed without proper drainage. |
Accessories
| Item | Download |
|---|---|
| Produktbilder | |
| Photometrie | |
| Installationsanleitung | |
| WE-EF Brochure 2021 - ETC300 LED Inground Luminaires | |
| Installation Instruction - ETC300 Blockout |
