FLA400 series

FLA460 LED Stirrup version

Choose a family:

L385×W260 mm | FLA440 LED Stirrup version L385×W260 mm | FLA441 LED Bracket version L530×W360 mm | FLA460 LED Stirrup version L530×W350 mm | FLA461 LED Bracket version

Home

Products

Pole-Mounted Luminaires

FLA460 LED

Family Spec Sheet Installation Instructions More Downloads

IP66, Class I. IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens, hinged. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter, including 6/6 kV surge protection. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Protractor scale incorporating locking pin for accurate and permanent aiming. Maximum spacing for streetlighting applications depends on wattage and light distribution: 5.5 to 9 times the mounting height.

Colours

RAL9004 Signal black

RAL9007 Grey aluminium

RAL7016 Anthracite grey

RAL9016 Traffic white

Material

Body	Marine-grade, die-cast aluminium alloy
Fasteners	PCS hardware
Gasket	Silicone CCG® Controlled Compression Gasket
Impact Protection	IK08
Ingress Protection	IP66
Finish	Powdercoat finish in black RAL 9004, grey aluminium RAL 9007 or white RAL 9016
Corrosion Protection	5CE
Mounting	Luminaire is factory-sealed and does not need to be opened during installation. Protractor scale incorporating locking pin for accurate and permanent aiming.

Electrical

Ballast / Driver	Integral EC electronic converter, including 6/6 kV surge protection
Power Supply	220-240V / 50-60 Hz

Additional Information

Lifetime	Ta=25° L90B10 > 90000h
BUG Rating	Please see individual Spec Sheets for classification of Backlight, Uplight and Glare

Light Distribution

Delivered Lumen

Colour Temperature

CRI

Part-ID	Light Distribution	Light Source	Delivered Lumen	CRI	Specifications
					Text	PDF
108-7800	pedestrian/bicycle lane [P65]	LED-36/72W / 700 mA - 3000 K	8098.5	80
108-7801	pedestrian/bicycle lane [P65]	LED-36/72W / 700 mA - 4000 K	8657	80
108-7720	asymmetric, side throw [S60]	LED-36/72W / 700 mA - 3000 K	8317.1	80
108-7721	asymmetric, side throw [S60]	LED-36/72W / 700 mA - 4000 K	8890.7	80
108-7722	asymmetric, side throw [S65]	LED-36/72W / 700 mA - 3000 K	8365.8	80
108-7723	asymmetric, side throw [S65]	LED-36/72W / 700 mA - 4000 K	8942.7	80
108-7724	asymmetric, side throw [S70]	LED-36/72W / 700 mA - 3000 K	8106	80
108-7725	asymmetric, side throw [S70]	LED-36/72W / 700 mA - 4000 K	8665	80
108-7728	asymmetric, forward throw [A60]	LED-36/72W / 700 mA - 3000 K	7799.2	80
108-7729	asymmetric, forward throw [A60]	LED-36/72W / 700 mA - 4000 K	8337.1	80
108-7726	rectangular, side throw [R65]	LED-36/72W / 700 mA - 3000 K	7621.6	80
108-7727	rectangular, side throw [R65]	LED-36/72W / 700 mA - 4000 K	8147.3	80
108-7802	pedestrian/bicycle lane [P65]	LED-36/108W / 1050 mA - 3000 K	12008.1	80
108-7803	pedestrian/bicycle lane [P65]	LED-36/108W / 1050 mA - 4000 K	12566.6	80
108-7730	asymmetric, side throw [S60]	LED-36/108W / 1050 mA - 3000 K	12332.2	80
108-7731	asymmetric, side throw [S60]	LED-36/108W / 1050 mA - 4000 K	12905.8	80
108-7732	asymmetric, side throw [S65]	LED-36/108W / 1050 mA - 3000 K	12404.4	80
108-7733	asymmetric, side throw [S65]	LED-36/108W / 1050 mA - 4000 K	12981.4	80
108-7734	asymmetric, side throw [S70]	LED-36/108W / 1050 mA - 3000 K	12019.2	80
108-7735	asymmetric, side throw [S70]	LED-36/108W / 1050 mA - 4000 K	12578.2	80
108-7738	asymmetric, forward throw [A60]	LED-36/108W / 1050 mA - 3000 K	11564.4	80
108-7739	asymmetric, forward throw [A60]	LED-36/108W / 1050 mA - 4000 K	12102.2	80
108-7736	rectangular, side throw [R65]	LED-36/108W / 1050 mA - 3000 K	11301.1	80
108-7737	rectangular, side throw [R65]	LED-36/108W / 1050 mA - 4000 K	11826.7	80
108-9780	pedestrian/bicycle lane [P65]	LED-36/72W / 700 mA - 2700 K	7540	80
108-9786	pedestrian/bicycle lane [P65]	LED-36/108W / 1050 mA - 2700 K	11449.6	80
108-9775	asymmetric, side throw [S60]	LED-36/72W / 700 mA - 2700 K	7743.5	80
108-9781	asymmetric, side throw [S60]	LED-36/108W / 1050 mA - 2700 K	11758.6	80
108-9776	asymmetric, side throw [S65]	LED-36/72W / 700 mA - 2700 K	7788.8	80
108-9782	asymmetric, side throw [S65]	LED-36/108W / 1050 mA - 2700 K	11827.5	80
108-9777	asymmetric, side throw [S70]	LED-36/72W / 700 mA - 2700 K	7546.9	80
108-9783	asymmetric, side throw [S70]	LED-36/108W / 1050 mA - 2700 K	11460.2	80
108-9779	asymmetric, forward throw [A60]	LED-36/72W / 700 mA - 2700 K	7261.3	80
108-9785	asymmetric, forward throw [A60]	LED-36/108W / 1050 mA - 2700 K	11026.5	80
108-9778	rectangular, side throw [R65]	LED-36/72W / 700 mA - 2700 K	7096	80
108-9784	rectangular, side throw [R65]	LED-36/108W / 1050 mA - 2700 K	10775.4	80
108-7721-70	asymmetric, side throw [S60]	LED-36/72W / 700 mA - 4000 K	10037.8	70

Showing 1 to 37 of 37 entries.

Accessories

Mounting Accessories

Optical Accessories

Part-ID	Title	Specifications
		Text	PDF
310-9124	Mounting Fitter TA1-76, Single
310-9125	Mounting Fitter TA2-76, double
