FLA400 series

FLA440 LED Stirrup version

Static White

Choose a family:

L385×W260 mm | FLA440 LED Stirrup version L385×W260 mm | FLA441 LED Bracket version L530×W360 mm | FLA460 LED Stirrup version L530×W350 mm | FLA461 LED Bracket version
Home
Products
Pole-Mounted Luminaires
FLA440 LED
Family Spec Sheet Installation Instructions More Downloads

IP66, Class I. IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens, hinged. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter, including 6/6 kV surge protection. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Protractor scale incorporating locking pin for accurate and permanent aiming. Maximum spacing for streetlighting applications depends on wattage and light distribution: 5.5 to 9 times the mounting height.

FLA440 LED Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK08
Ingress ProtectionIP66
FinishPowdercoat finish in black RAL 9004, grey aluminium RAL 9007 or white RAL 9016
Corrosion Protection5CE
MountingLuminaire is factory-sealed and does not need to be opened during installation. Protractor scale incorporating locking pin for accurate and permanent aiming.
Electrical
Ballast / DriverIntegral EC electronic converter, including 6/6 kV surge protection
Power Factor> 0.9
Power Supply220-240V / 50-60 Hz
Additional Information
LifetimeTa=25° L90B10 > 90000h
BUG RatingPlease see individual Spec Sheets for classification of Backlight, Uplight and Glare

Delivered Lumen

To

Wattage

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
108-7795pedestrian/bicycle lane [P65]LED-18/36W / 700 mA - 3000 K4049.280
108-7796pedestrian/bicycle lane [P65]LED-18/36W / 700 mA - 4000 K4328.580
108-7699asymmetric, side throw [S60]LED-18/36W / 700 mA - 3000 K4158.580
108-7700asymmetric, side throw [S60]LED-18/36W / 700 mA - 4000 K4445.380
108-7701asymmetric, side throw [S65]LED-18/36W / 700 mA - 3000 K4182.980
108-7702asymmetric, side throw [S65]LED-18/36W / 700 mA - 4000 K4471.480
108-7703asymmetric, side throw [S70]LED-18/36W / 700 mA - 3000 K405380
108-7704asymmetric, side throw [S70]LED-18/36W / 700 mA - 4000 K4332.580
108-7707asymmetric, forward throw [A60]LED-18/36W / 700 mA - 3000 K3899.680
108-7708asymmetric, forward throw [A60]LED-18/36W / 700 mA - 4000 K4168.680
108-7705rectangular, side throw [R65]LED-18/36W / 700 mA - 3000 K3810.880
108-7797pedestrian/bicycle lane [P65]LED-18/54W / 1050 mA - 3000 K6004.180
108-7798pedestrian/bicycle lane [P65]LED-18/54W / 1050 mA - 4000 K6283.380
108-7709asymmetric, side throw [S60]LED-18/54W / 1050 mA - 3000 K6166.180
108-7710asymmetric, side throw [S60]LED-18/54W / 1050 mA - 4000 K6452.980
108-7711asymmetric, side throw [S65]LED-18/54W / 1050 mA - 3000 K6202.280
108-7712asymmetric, side throw [S65]LED-18/54W / 1050 mA - 4000 K6490.780
108-7713asymmetric, side throw [S70]LED-18/54W / 1050 mA - 3000 K6009.680
108-7714asymmetric, side throw [S70]LED-18/54W / 1050 mA - 4000 K6289.180
108-7717asymmetric, forward throw [A60]LED-18/54W / 1050 mA - 3000 K5782.280
108-7718asymmetric, forward throw [A60]LED-18/54W / 1050 mA - 4000 K6051.180
108-7715rectangular, side throw [R65]LED-18/54W / 1050 mA - 3000 K5650.580
108-7716rectangular, side throw [R65]LED-18/54W / 1050 mA - 4000 K5913.380
108-7706rectangular, side throw [R65]LED-18/36W / 700 mA - 4000 K4073.680
108-9129rectangular, side throw [R65]LED-18/54W / 1050 mA - 2700 K5387.780
108-9123rectangular, side throw [R65]LED-18/36W / 700 mA - 2700 K354880
108-9130asymmetric, forward throw [A60]LED-18/54W / 1050 mA - 2700 K5513.280
108-9124asymmetric, forward throw [A60]LED-18/36W / 700 mA - 2700 K3630.780
108-9128asymmetric, side throw [S70]LED-18/54W / 1050 mA - 2700 K5730.180
108-9122asymmetric, side throw [S70]LED-18/36W / 700 mA - 2700 K3773.580
108-9121asymmetric, side throw [S65]LED-18/36W / 700 mA - 2700 K3894.480
108-9127asymmetric, side throw [S65]LED-18/54W / 1050 mA - 2700 K5913.780
108-9126asymmetric, side throw [S60]LED-18/54W / 1050 mA - 2700 K5879.380
108-9120asymmetric, side throw [S60]LED-18/36W / 700 mA - 2700 K3871.780
108-9125pedestrian/bicycle lane [P65]LED-18/36W / 700 mA - 2700 K377080
108-9131pedestrian/bicycle lane [P65]LED-18/54W / 1050 mA - 2700 K5724.880
Showing 1 to 36 of 36 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
147-0543Pole clamp TS1-2/M12, single (Ø 76-89)
147-0545Pole clamp TS2-2/M12, double (Ø 76-89)
147-0643Pole clamp TS1-2/M12, single (Ø 114-140)
147-0674Pole clamp TS2-2/M12, double (Ø 114-140)
