FLA400 series

FLA441 LED Bracket version

Static White

Choose a family:

L385×W260 mm | FLA440 LED Stirrup version L385×W260 mm | FLA441 LED Bracket version L530×W360 mm | FLA460 LED Stirrup version L530×W350 mm | FLA461 LED Bracket version
Home
Products
Pole-Mounted Luminaires
FLA441 LED Bracket version
Family Spec Sheet Installation Instructions More Downloads

IP66. Class I. IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens, hinged. Silicone CCG® Controlled Compression Gasket. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. LED board can be easily removed for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Maximum spacing for streetlighting applications depends on wattage and light distribution: 5.5 to 9 times the mounting height.

FLA441 LED Bracket version Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK08
Ingress ProtectionIP66
FinishPowdercoat finish in Classic Silver, black RAL 9004, grey aluminium RAL 9007 or white RAL 9016
Corrosion Protection5CE
Electrical
Ballast / DriverIntegral EC electronic converter, including 6/6 kV surge protection
Additional Information
BUG RatingPlease see individual Spec Sheets for classification of Backlight, Uplight and Glare

Delivered Lumen

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
108-7805pedestrian/bicycle lane [P65]LED-18/36W / 700 mA - 3000 K4049.180
108-7806pedestrian/bicycle lane [P65]LED-18/36W / 700 mA - 4000 K4328.480
108-7741asymmetric, side throw [S60]LED-18/36W / 700 mA - 3000 K4158.480
108-7742asymmetric, side throw [S60]LED-18/36W / 700 mA - 4000 K4445.280
108-7743asymmetric, side throw [S65]LED-18/36W / 700 mA - 3000 K4182.780
108-7744asymmetric, side throw [S65]LED-18/36W / 700 mA - 4000 K4471.280
108-7745asymmetric, side throw [S70]LED-18/36W / 700 mA - 3000 K4052.880
108-7746asymmetric, side throw [S70]LED-18/36W / 700 mA - 4000 K4332.480
108-7749asymmetric, forward throw [A60]LED-18/36W / 700 mA - 3000 K3899.580
108-7750asymmetric, forward throw [A60]LED-18/36W / 700 mA - 4000 K4168.480
108-7747rectangular, side throw [R65]LED-18/36W / 700 mA - 3000 K3810.780
108-7748rectangular, side throw [R65]LED-18/36W / 700 mA - 4000 K4073.580
108-7807pedestrian/bicycle lane [P65]LED-18/54W / 1050 mA - 3000 K6003.980
108-7808pedestrian/bicycle lane [P65]LED-18/54W / 1050 mA - 4000 K6283.380
108-7751asymmetric, side throw [S60]LED-18/54W / 1050 mA - 3000 K6165.980
108-7752asymmetric, side throw [S60]LED-18/54W / 1050 mA - 4000 K6452.980
108-7753asymmetric, side throw [S65]LED-18/54W / 1050 mA - 3000 K620280
108-7754asymmetric, side throw [S65]LED-18/54W / 1050 mA - 4000 K6490.780
108-7755asymmetric, side throw [S70]LED-18/54W / 1050 mA - 3000 K6009.480
108-7756asymmetric, side throw [S70]LED-18/54W / 1050 mA - 4000 K6289.180
108-7759asymmetric, forward throw [A60]LED-18/54W / 1050 mA - 3000 K578280
108-7760asymmetric, forward throw [A60]LED-18/54W / 1050 mA - 4000 K6051.180
108-7757rectangular, side throw [R65]LED-18/54W / 1050 mA - 3000 K5650.380
108-7758rectangular, side throw [R65]LED-18/54W / 1050 mA - 4000 K5913.380
Showing 1 to 24 of 24 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
310-9134Single column fitter EB1-102
310-9135Double column fitter EB2-102
