RGBW Colour Changer. IP69. IK10+. Stainless steel construction including PCS hardware. Safety glass lens; max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Factory-sealed termination chamber complete with cable gland and 0.5 m of flexible PVC free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. LED circuit board with WE-EF Colour Boost Technology. DMX Interface. For other control interface options to suit specific project requirements, contact WE-EF. Luminaire installation blockout and sealable junction box included in supply.

ETC330-FS CC LED Schematics
Couleurs
Stainless Steel
Description du matériel
CorpsStainless steel construction
VisseriePCS hardware
JointSilicone rubber gasket
IKIK10+
IPIP69
MontageLuminaire installation blockout and sealable junction box included in supply
Description électrique
DriverIntegral EC electronic converter with DMX Interface
CâbleComplete with cable gland and 0.5 m of flexible PVC-free cable
Informations complémentaires
Code produitDistribution photométriqueSource lumineuseDonnées en sortie de luminaireIRCCaractéristiquesPhotométrie
TextePDF
185-7792symmetric, wide beam [B]LED-12/19W - RGBW/4K1330.620/80
185-7793symmetric, medium beam [M]LED-12/19W - RGBW/4K1326.720/80
185-7884symmetric, wallgrazer [A6]LED-12/19W - RGBW/4K1445.520/80
Affichage de 1 à 3 sur 3 résultats

Accessories

Code produitTitreCaractéristiques
TextePDF
185-0325Installation cover BE
ItemDownload
Images du produit
Photométrie
Instructions d'installation
