ETC340-FS CC LED
RGBW Colour Changer. IP69. IK10+. Stainless steel construction including PCS hardware. Safety glass lens; max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Factory-sealed termination chamber complete with cable gland and 0.5 m of flexible PVC free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. LED circuit board with WE-EF Colour Boost Technology. DMX Interface. For other control interface options to suit specific project requirements, contact WE-EF. Luminaire installation blockout and sealable junction box included in supply.
Colours
Material
| Body | Stainless steel construction |
| Fasteners | PCS hardware |
| Gasket | Silicone rubber gasket |
| Impact Protection | IK10+ |
| Ingress Protection | IP69 |
| Mounting | Luminaire installation blockout and sealable junction box included in supply |
Electrical
| Ballast / Driver | Integral EC electronic converter with DMX Interface |
| Cable | Complete with cable gland and 0.5 m of flexible PVC-free cable |
| Power Supply | 230V / 50 Hz |
Additional Information
| Warranty | The product is supplied with 10-year warranty. Please refer to the LED Warranty Statement located on www.we-ef.com for further details. |
Accessories
| Item | Download |
|---|---|
| Product Images | |
| Photometrics | |
| Installation Instructions |
