ZFY200

600 mm

1.000 mm

ZFY230 LED-FT ZFY250 LED-FT

Home

Products

Bollards and Pathway Luminaires

ZFY250 LED-FT II

Family Spec Sheet

Available as an Impact-Rated Bollard (SC40, PU40, M30, M30 Shallow), specify impact designation with your order, options below. IP66. Class I. IK10. Marine-grade, all aluminum construction. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Polycarbonate main lens. CAD-optimized indirect optics for superior illumination and glare control. Integral driver in thermally separated compartment. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Pre-wired post complete with cable connecting box and fuse for mains connection. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Colors

RAL9004 Black

RAL9006 White

RAL9007 Grey Metallic

RAL7016 Anthracite grey

RAL9016 White

RAL8019 Dark Bronze

Powdercoat finish available in 35 different colours

Material

Body	Marine-grade, all aluminum construction
Fasteners	PCS Polymer Coated Stainless Steel Hardware
Gasket	Silicone CCG® Controlled Compression Gasket
Impact Protection	IK10
Ingress Protection	IP66
Finish
Corrosion Protection
Mounting	Anchor Bolts Included, Installation Template Provided With Order

Electrical

Ballast / Driver	Integral EC electronic converter
Cable
Power Factor
Power Supply	Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Surge Protection	Integral 10kV Surge Protector

Additional Information

Lifetime	Ta=25°/40° L70B50 > 50000h

Light Distribution

Delivered Lumen

Wattage

Colour Temperature

CRI

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
117-0204	symmetric distribution [C60]	LED-FT-17W (4000K)	790.4	80
117-0203	symmetric distribution [C60]	LED-FT-17W (3000K)	758.2	80
117-0205	symmetric distribution [C60]	LED-FT-24W (3000K)	1042.3	80
117-0206	symmetric distribution [C60]	LED-FT-24W (4000K)	1086.7	80
117-0205	asymmetric, forward-throw, one-sided	LED-FT-24W (3000K)	491.7	80
117-0206	asymmetric, forward-throw, one-sided	LED-FT-24W (4000K)	512.9	80
117-0203	asymmetric, forward-throw, one-sided	LED-FT-17W (3000K)	384.1	80
117-0204	asymmetric, forward-throw, one-sided	LED-FT-17W (4000K)	400.3	80
117-0203	symmetric distribution [C60]	LED-FT-17W (2700K)	724.9	80
117-0327	symmetric distribution [C60]	LED-FT-24W (2700K)	1000.3	80
114-6904	Blank Head [BLANK]	BLANK Head		NA

Showing 1 to 11 of 11 Entries
