ZFY250 LED-FT I

Family Spec Sheet

IP66. Class I. IK10. Marine-grade, all aluminum construction. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Polycarbonate main lens. CAD-optimized indirect optics for superior illumination and glare control. Integral driver in thermally separated compartment. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Pre-wired post complete with cable connecting box and fuse for mains connection. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Colors

Material

Body: Marine-grade all-aluminium construction

Fasteners: PCS Polymer Coated Stainless Steel Hardware

Gasket: Silicone CCG® Controlled Compression Gasket

Impact Protection: IK10

Ingress Protection: IP66

Finish:

Corrosion Protection: 5CE

Mounting: Anchor Bolts Included, Installation Template Provided With Order

Electrical

Ballast / Driver: Integral EC electronic converter

Cable:

Power Factor:

Power Supply: Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.

Surge Protection: Integral 10kV Surge Protector

Additional Information

Lifetime: Ta=25°/40° L70B50 > 50000h

Light Distribution

Delivered Lumen

Wattage

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
117-0209	symmetric distribution [C60]	LED-FT-24W (3000K)	1042.3	80
117-0208	symmetric distribution [C60]	LED-FT-17W (4000K)	790.4	80
117-0210	symmetric distribution [C60]	LED-FT-24W (4000K)	1086.7	80
117-0207	symmetric distribution [C60]	LED-FT-17W (3000K)	758.2	80
117-0207	asymmetric, forward-throw, one-sided	LED-FT-17W (3000K)	384.1	80
117-0208	asymmetric, forward-throw, one-sided	LED-FT-17W (4000K)	400.3	80
117-0209	asymmetric, forward-throw, one-sided	LED-FT-24W (3000K)	491.7	80
117-0210	asymmetric, forward-throw, one-sided	LED-FT-24W (4000K)	512.9	80
117-0324	symmetric distribution [C60]	LED-FT-17W (2700K)	724.9	80
117-0325	symmetric distribution [C60]	LED-FT-24W (2700K)	1000.3	80

Showing 1 to 10 of 10 Entries
