Impact-Rated Bollard. IP66. Class I. IK10. Marine-grade, all aluminum construction. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Polycarbonate main lens. CAD-optimized indirect optics for superior illumination and glare control. Integral driver in thermally separated compartment. Factory-installed LED circuit board. Crash rated for small vehicles travelling up to 40mph (SC40), pick-up vehicles travelling up to 40mph (PU40), and medium-duty vehicles travelling up to 30mph (M30). Pre-wired post complete with cable connecting box and fuse for mains connection. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

ZFY230 LED-FT Security Bollard Schematics
Colours
RAL9004 Black
RAL9007 Grey Metallic
RAL9016 White
RAL8019 Dark Bronze
Material
BodyMarine-grade, all-aluminium construction
FastenersPCS Polymer Coated Stainless Steel Hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK10
Ingress ProtectionIP66
Corrosion Protection5CE
Electrical
Ballast / DriverIntegral EC electronic converter
Power SupplyIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Surge ProtectionIntegral 10kV Surge Protector
Additional Information
LifetimeTa=25°/40° L70B50 > 90000h
BUG RatingPlease see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Delivered Lumen

To

Wattage

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
117-6609Blank Head [BLANK]BLANK HeadNA
117-6608Blank Head [BLANK]BLANK HeadNA
117-6601symmetric distribution [C60]LED-FT 12W (3000K)758.780
117-6600symmetric distribution [C60]LED-FT 12W (3000K)758.780
117-6603symmetric distribution [C60]LED-FT 12W (4000K)799.480
117-6602symmetric distribution [C60]LED-FT 12W (4000K)799.480
117-6605symmetric distribution [C60]LED-FT-17W (3000K)1136.280
117-6604symmetric distribution [C60]LED-FT-17W (3000K)1136.280
117-6607symmetric distribution [C60]LED-FT-17W (4000K)1184.380
117-6606symmetric distribution [C60]LED-FT-17W (4000K)1184.380
Showing 1 to 10 of 10 entries.
