FLC311 Space frame

Back
Regular Frame Regular Frame
Space Frame Space Frame
Family Spec Sheet
58 mm 58 mm
85 mm 85 mm
115 mm 115 mm

IP66. IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation.
Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. 6-12W / 120-277V / 0-10V Dimming. Optical accessories are factory-installed. To be specified at time of ordering. Including terminal box, for mounting on ø 1.89-2.36 in pipes or space frames.

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK08
SchutzartIP66
Abdeckung
Korrosionsschutz5CE
BefestigungIncluding terminal box, for mounting on ø 1.89-2.36 in pipes or space frames

Elektrik

LED TreiberIntegral [ECG] electronic driver 120V-277V.
Kabel
Leistungsfaktor
Netz
Überspannungsschutz

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
145-7744symmetric, wide beam [W]LED-3/6W / 180 mA - 2700 K595.480electronic gear2.50
145-7747symmetric, wide beam [W]LED-3/6W / 180 mA - 3000 K595.480electronic gear2.50
145-7750symmetric, wide beam [W]LED-3/6W / 180 mA - 4000 K641.280electronic gear2.50
145-7745symmetric, wide beam [W]LED-3/9W / 250 mA - 2700 K835.880electronic gear2.50
145-7748symmetric, wide beam [W]LED-3/9W / 250 mA - 3000 K835.880electronic gear2.50
145-7751symmetric, wide beam [W]LED-3/9W / 250 mA - 4000 K893.180electronic gear2.50
145-7746symmetric, wide beam [W]LED-3/12W / 350 mA - 2700 K1122.180electronic gear2.50
145-7749symmetric, wide beam [W]LED-3/12W / 350 mA - 3000 K1122.180electronic gear2.50
145-7752symmetric, wide beam [W]LED-3/12W / 350 mA - 4000 K1213.780electronic gear2.50
145-7753symmetric, medium beam [M]LED-3/6W / 180 mA - 2700 K600.480electronic gear2.50
145-7756symmetric, medium beam [M]LED-3/6W / 180 mA - 3000 K600.480electronic gear2.50
145-7759symmetric, medium beam [M]LED-3/6W / 180 mA - 4000 K646.680electronic gear2.50
145-7754symmetric, medium beam [M]LED-3/9W / 250 mA - 2700 K842.980electronic gear2.50
145-7757symmetric, medium beam [M]LED-3/9W / 250 mA - 3000 K842.980electronic gear2.50
145-7760symmetric, medium beam [M]LED-3/9W / 250 mA - 4000 K900.680electronic gear2.50
145-7755symmetric, medium beam [M]LED-3/12W / 350 mA - 2700 K1131.680electronic gear2.50
145-7758symmetric, medium beam [M]LED-3/12W / 350 mA - 3000 K1131.680electronic gear2.50
145-7761symmetric, medium beam [M]LED-3/12W / 350 mA - 4000 K122480electronic gear2.50
145-7762symmetric, very narrow beam [VN]LED-3/6W / 180 mA - 2700 K605.280electronic gear2.50
145-7765symmetric, very narrow beam [VN]LED-3/6W / 180 mA - 3000 K605.280electronic gear2.50
145-7768symmetric, very narrow beam [VN]LED-3/6W / 180 mA - 4000 K651.780electronic gear2.50
145-7763symmetric, very narrow beam [VN]LED-3/9W / 250 mA - 2700 K849.680electronic gear2.50
145-7766symmetric, very narrow beam [VN]LED-3/9W / 250 mA - 3000 K849.680electronic gear2.50
145-7769symmetric, very narrow beam [VN]LED-3/9W / 250 mA - 4000 K907.880electronic gear2.50
145-7764symmetric, very narrow beam [VN]LED-3/12W / 350 mA - 2700 K1140.580electronic gear2.50
Showing 1 to 25 of 63 Entries
