FLC301 Space frame

FLC301 Space frame

Family Spec Sheet

IP66. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. Including terminal box, for mounting on ø 1.89-2.36 in pipes or space frames. 120V mains voltage version only, ON-OFF Class I.

FLC301 Space frame Schematics
Colors
RAL9004 Black
RAL9006 White
RAL9007 Grey Metallic
RAL7016 Anthracite grey
RAL9016 White
Powdercoat finish available in 35 different colours
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK07
Ingress ProtectionIP66
Finish
Corrosion Protection5CE
MountingIncluding terminal box, for mounting on ø 2.28 x 3.94 in pipes or space frames
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-separated compartment
Cable
Power Factor
Power Supply
Surge Protection
Additional Information
LifetimeTa=25°/40° L90B10 > 90000h

Delivered Lumen

To
Part-IDLight DistributionLight SourceLumenCRIOpen DataPDFIES, LDT, ULD
145-7270symmetric, wide beam [W]LED-1/4W / 350 mA – 2700 K379.180
145-7271symmetric, wide beam [W]LED-1/4W / 350 mA – 3000 K379.180
145-7272symmetric, wide beam [W]LED-1/4W / 350 mA – 4000 K410.180
145-7273symmetric, medium beam [M]LED-1/4W / 350 mA – 2700 K398.480
145-7274symmetric, medium beam [M]LED-1/4W / 350 mA – 3000 K398.480
145-7275symmetric, medium beam [M]LED-1/4W / 350 mA – 4000 K43180
145-7276symmetric, narrow beam [N]LED-1/4W / 350 mA – 2700 K415.280
145-7277symmetric, narrow beam [N]LED-1/4W / 350 mA – 3000 K415.280
145-7278symmetric, narrow beam [N]LED-1/4W / 350 mA – 4000 K449.180
145-7279symmetric, very narrow beam [VN]LED-1/4W / 350 mA – 2700 K415.580
145-7280symmetric, very narrow beam [VN]LED-1/4W / 350 mA – 3000 K415.580
145-7281symmetric, very narrow beam [VN]LED-1/4W / 350 mA – 4000 K449.580
145-7282symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-1/4W / 350 mA – 2700 K382.280
145-7283symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-1/4W / 350 mA – 3000 K382.280
145-7284symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-1/4W / 350 mA – 4000 K411.680
145-7279linear spread, very narrow beam [VN]LED-1/4W / 350 mA – 2700 K384.780
145-7280linear spread, very narrow beam [VN]LED-1/4W / 350 mA – 3000 K384.780
145-7281linear spread, very narrow beam [VN]LED-1/4W / 350 mA – 4000 K416.180
145-7282linear spread, very narrow beam, 'sharp cut-off'LED-1/4W / 350 mA – 2700 K343.580
145-7283linear spread, very narrow beam, 'sharp cut-off'LED-1/4W / 350 mA – 3000 K343.580
145-7284linear spread, very narrow beam, 'sharp cut-off'LED-1/4W / 350 mA – 4000 K369.980
145-7273wallwashLED-1/4W / 350 mA – 2700 K331.780
145-7274wallwashLED-1/4W / 350 mA – 3000 K331.780
145-7275wallwashLED-1/4W / 350 mA – 4000 K358.880
