RLS410 LED

Back
Family Spec Sheet
100 mm 100 mm 180 mm 180 mm
100 mm 100 mm 270 mm 270 mm

IP66. Class I. Class II on request. IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Optional 2200 K version up to max. 1050mA available. To be specified at time of ordering.
Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Luminaire can be mounted for up or down lighting.

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK08
SchutzartIP66
Abdeckung
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberStandard. Optional DALI version available. To be specified at time of ordering.
Kabel
Leistungsfaktor> 0.9
Netz220-240V / 50-60 Hz
Überspannungsschutz1/2 kV

Weitere Eigenschaften

LifetimeTa=25° L90B10 > 90000h

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
131-9960rectangular, side throw [R45]LED-3/6W / 700 mA - 3000 K548.280EC1.90
131-9961rectangular, side throw [R45]LED-3/6W / 700 mA - 4000 K58680EC1.90
131-9601rectangular, side throw [R45]LED-3/6W / 700 mA - 2700 K510.480EC1.90
131-9962rectangular, side throw [R45]LED-3/9W / 1050 mA - 3000 K770.180EC1.90
131-9963rectangular, side throw [R45]LED-3/9W / 1050 mA - 4000 K805.980EC1.90
131-9602rectangular, side throw [R45]LED-3/9W / 1050 mA - 2700 K734.380EC1.90
131-9964rectangular, side throw [R45]LED-3/13W / 1400 mA - 3000 K98580EC1.90
131-9965rectangular, side throw [R45]LED-3/13W / 1400 mA - 4000 K1029.880EC1.90
131-9603rectangular, side throw [R45]LED-3/13W / 1400 mA - 2700 K931.380EC1.90
131-9966symmetric, medium beam [M]LED-3/6W / 700 mA - 3000 K698.580EC1.90
131-9967symmetric, medium beam [M]LED-3/6W / 700 mA - 4000 K746.780EC1.90
131-9604symmetric, medium beam [M]LED-3/6W / 700 mA - 2700 K650.480EC1.90
131-9968symmetric, medium beam [M]LED-3/9W / 1050 mA - 3000 K1019.980EC1.90
131-9969symmetric, medium beam [M]LED-3/9W / 1050 mA - 4000 K1067.380EC1.90
131-9605symmetric, medium beam [M]LED-3/9W / 1050 mA - 2700 K972.480EC1.90
131-9970symmetric, medium beam [M]LED-3/13W / 1400 mA - 3000 K1304.580EC1.90
131-9971symmetric, medium beam [M]LED-3/13W / 1400 mA - 4000 K1363.880EC1.90
131-9606symmetric, medium beam [M]LED-3/13W / 1400 mA - 2700 K1233.380EC1.90
131-9972symmetric, narrow beam [E]LED-3/6W / 700 mA - 3000 K656.980EC1.90
131-9973symmetric, narrow beam [E]LED-3/6W / 700 mA - 4000 K702.280EC1.90
131-9607symmetric, narrow beam [E]LED-3/6W / 700 mA - 2700 K611.680EC1.90
131-9974symmetric, narrow beam [E]LED-3/9W / 1050 mA - 3000 K1034.380EC1.90
131-9975symmetric, narrow beam [E]LED-3/9W / 1050 mA - 4000 K1082.480EC1.90
131-9608symmetric, narrow beam [E]LED-3/9W / 1050 mA - 2700 K986.280EC1.90
131-9976symmetric, narrow beam [E]LED-3/13W / 1400 mA - 3000 K1322.980EC1.90
Showing 1 to 25 of 27 Entries
